8A-9901-00/A
Fuel drain hose
Description
8A-9901-00/A fuel drain hose
The 8A-9901-00/A is a ground-servicing hose assembly used to drain fuel from a helicopter into a refueling vehicle or another approved receiving system. It is associated with Mi-8 / Mi-17 maintenance equipment and is not a permanently installed fuel-system hose. The slash suffix is retained because it identifies the recorded product version.
The maintenance procedure describes connecting one end of the hose to the aircraft fuel drain valve. When fuel is drained to a refueler, the opposite end is joined to the adapter hose or nozzle supplied for that vehicle and secured by the appropriate coupling. This controlled path helps keep the operation contained and reduces the risk of using improvised connections.
Full descriptionCollapse description
Connection to the aircraft fuel system
The exact drain point, valve sequence, bonding requirements and approved fuel grade come from the aircraft and refueler documentation. The hose itself does not authorize a drain operation. Maintenance personnel must ensure that the receiving vehicle is suitable, the system is depressurized as required and the work area complies with fire-safety and environmental procedures.
Because the assembly connects aircraft and ground equipment, both interfaces matter. Coupling geometry, sealing surfaces, protective caps and the refueler adapter should be checked before ordering. The related 8A-9901-00 product on the site is treated as a separate designation; interchangeability with 8A-9901-00/A has not been established.
Aircraft-family reference: Mil Mi-8. This external reference does not replace the approved maintenance manual.
Inspection and configuration checks
Before use, inspect the complete hose for cuts, cracking, swelling, abrasion, exposed reinforcement and permanent flattening. Check the couplings, clamps, safety wire, caps and seals for damage or contamination. Fuel hoses require particular attention to cleanliness, because foreign material introduced during a drain or transfer operation can contaminate the receiving system.
The complete designation should be stated as 8A-9901-00/A. Dotted and spaced forms are recorded only to support search and legacy documents. The delivery set has not been independently confirmed, so an inquiry should identify whether refueler adapters, protective caps, seals or documentation must be included rather than assuming that every accessory shown in a similar set is supplied.
Supply and ordering information
This product remains Pre-Order with its existing price unchanged. The card records Condition: New, Warranty: 6 Months and YOM: 2026. The estimated 90–120 day lead time is subject to confirmation. Storage life, pressure or leakage test status and fuel compatibility must be supported by the documents delivered with the actual hose.
For a useful quotation, provide the helicopter modification, drain procedure reference, required quantity and refueler connection type. Related ground-support products are linked to help navigate the maintenance category. They may be used during the same servicing event, but they do not replace the 8A-9901-00/A hose assembly.
More items are available in the Ground Support Equipment category.
Related products in this batch: 246-9977-00, 8AT-9907-00, 56-9918-00, 8MT-9925-00. They belong to the same ground-support category but are not interchangeable.
Technical details
- Product Type
- Fuel drain hose assembly to refueler
- Designation
- 8A-9901-00/A
- Alternative Designations
- 8A.9901.00/A; 8A 9901 00 A; 8А-9901-00/А; 8А.9901.00/А
- Function
- Controlled draining of helicopter fuel into a refueling vehicle or approved receiving system
- Application / Where Used
- Mi-8 / Mi-17 family ground maintenance where specified by the aircraft documentation
All specificationsCollapse specifications
- System / Installation Area
- Aircraft fuel drain valve and ground refueler interface
- Operating Method
- One end connects to the aircraft fuel drain valve; the opposite end connects through the approved adapter hose or nozzle to the refueler
- Working Medium
- Aviation fuel; exact approved grade follows the aircraft maintenance documentation
- Delivery Set
- Not independently confirmed; verify hose, couplings, caps, seals and refueler adapter requirements
- Interchangeability
- Not confirmed with 8A-9901-00 or similarly numbered hose assemblies
- Estimated Lead Time
- 90–120 days, subject to confirmation
- Technical Documentation
- Mi-8 / Mi-17 fuel-system maintenance procedure and delivery records when available
