UNCH-037M

UNCH-037M board in the A-037 radio altimeter

The UNCH-037M is a low-frequency amplifier board used inside airborne radio altimeter equipment. It is included in the radio component set of the A-037 radio altimeter and is used in A-037-1A, A-037-1V and A-037-1G receiver configurations, as well as in the PP-5M receiver. The board is not a standalone device. It operates only as part of the complete radio altimeter equipment together with the receiving, measuring, microwave and power-supply modules.

Low-frequency amplification role of UNCH-037M

The UNCH-037M operates in the receiving and measurement chain of the radio altimeter. Its main function is amplification of low-frequency signals formed during processing of the reflected radio signal. In a radio altimeter, the reflected microwave signal is received and converted into a lower-frequency measurement signal. The UNCH-037M amplifies this signal so it can be used by the following measuring and output-signal formation circuits of the A-037 system.

UNCH-037M in A-037-1 receiver configurations

The UNCH-037M board is compatible with A-037-1A, A-037-1V and A-037-1G receiver configurations, where specified by the radio altimeter documentation. These configurations may differ by system variant, indicator type, measurement range and aircraft installation, but the UNCH-037M remains part of the internal low-frequency receiving path. For repair or replacement, compatibility should be confirmed by the receiver version, A-037 variant, board marking and applicable technical documentation.

Use of UNCH-037M in PP-5M receiver

In addition to the A-037 radio altimeter, the UNCH-037M board is also associated with the PP-5M receiver. In this application, it works as an internal low-frequency amplifier board in the receiver-related signal path. Since A-037 and PP-5M equipment may use similar internal boards, the exact applicability should be checked by the product passport and receiver documentation. This is especially important when the board is supplied separately from a complete receiver assembly.

Functional position in the measurement chain

The UNCH-037M is located after the microwave receiving and conversion stages, where the system has already formed a low-frequency signal related to flight height. The board amplifies this signal before it is used by the measuring unit and output circuits of the radio altimeter. A fault in this board may affect sensitivity, stability of height indication, TEST operation or fault-signal formation. For this reason, the UNCH-037M should be checked together with the receiving module, measuring board, power supply and connected wiring.

Technical data status of UNCH-037M

According to the product passport, separate basic technical data for the UNCH-037M board are not specified. Its functional purpose, operating modes and electrical characteristics are defined at the system level of the A-037 radio altimeter and regulated by the applicable technical documentation. This is typical for an internal functional board: it is not accepted as a separate radio device, but is tested and evaluated as part of the complete receiver or radio altimeter equipment.

Installation and supply notes for UNCH-037M

Structurally, the UNCH-037M is manufactured as an electronic low-frequency amplifier board installed inside radio altimeter receiver assemblies. During inspection, the board should be checked for connector condition, soldering quality, component damage, corrosion, contamination, overheating marks and storage-related defects. Since it is an avionics electronic board, handling should be done with proper antistatic precautions. For procurement, the full designation UNCH-037M should be used, with the required receiver configuration clearly stated

Product Name: Low-Frequency Amplifier Board
Part Number: UNCH-037M
Product Type: Low-frequency amplifier board / electronic amplifier board
Function: Amplification of low-frequency signals within the radio altimeter
System Application: A-037 radio altimeter
Compatible Receivers: A-037-1A; A-037-1V; A-037-1G
Additional Application: PP-5M receiver
Operating Role: Amplification of low-frequency measurement signals in the receiving and measurement chain
Associated Signal Path: Low-frequency signal formed after microwave reception and conversion
Basic Technical Data: Not specified separately
Electrical / Functional Characteristics: Defined at A-037 radio altimeter system level
Service Life: Corresponds to A-037 radio altimeter
Storage Life: Corresponds to A-037 radio altimeter
Warranty Operating Time: 2000 hours
Warranty Storage Period: 2 years
Design: Electronic low-frequency amplifier board
Operation Mode: Installed inside radio altimeter equipment; not used as a standalone device
Condition: As applicable
Alternate Designations: UNCH-037M; UNCH 037M; UNCH-037 M; UNCh-037M
Technical Documentation: Product passport VRO.015.000 ET and applicable A-037 radio altimeter documentation
