IZH6.122.534 / Block 5

IZH6.122.534 shock-mount frame for Baklan radio equipment

IZH6.122.534 is an aircraft shock-mount frame used as a standard mounting element for onboard VHF radio station equipment of the Baklan family, including Baklan-20, Baklan-20D and related configurations where applicable. The frame provides mechanical installation and vibration isolation of the radio transceiver unit inside the aircraft structure. It is used as Block 5 in the radio station set and forms the mechanical base for secure equipment fixation during aircraft operation.

Vibration protection through IZH6.122.534

The IZH6.122.534 frame protects the installed radio unit from vibration, shock loads and structural movement that occur during flight and ground operation. Aircraft radio equipment is exposed to continuous vibration, temperature changes and mechanical loads, especially on helicopters and transport aircraft. The shock-mount frame reduces the transmission of these loads to the transceiver, connectors and internal electronic assemblies, helping maintain reliable operation and service life of the radio station.

Mechanical design of IZH6.122.534

The frame is designed as a metal mounting platform with damping elements and locking devices for secure fixation of the radio station block. The transceiver is installed on the frame and fixed in the required position according to the aircraft installation documentation. Depending on the radio station configuration, single or paired frame versions may be used. In paired installations, two transceivers and related auxiliary units may be mounted as part of a duplicated radio communication set.

IZH6.122.534 in the Baklan-20 / Baklan-20D set

Within the Baklan radio station set, the IZH6.122.534 frame works as a structural support element. It does not receive, transmit, amplify or process radio signals. Its role is purely mechanical: to provide a stable base for the transceiver and related equipment, ensure correct positioning and protect the radio unit from vibration. The complete radio station may also include the transceiver, remote control panel, low-frequency amplifier, cables, connectors and aircraft VHF antenna connection.

Aircraft installation of IZH6.122.534

The IZH6.122.534 shock-mount frame is installed in the aircraft radio equipment compartment, technical compartment or radio equipment rack according to the aircraft layout. On fixed-wing aircraft, the frame may be installed on equipment shelves or racks in technical compartments. On Mi-8 / Mi-17 family helicopters, it may be mounted on the radio equipment rack in the cockpit or near the passage to the cargo cabin, depending on modification and documentation. Exact location must be confirmed by aircraft technical documentation.

Identification and ordering of IZH6.122.534

The frame may be referenced as IZH6.122.534, ИЖ6.122.534, Block 5, Baklan shock-mount frame, Baklan-20 mounting frame or radio station shock-mount frame. Related frame designation IZH6.122.532 may also appear in supply lists depending on configuration. For correct supply, it is useful to specify the aircraft type, radio station version, single or paired installation, required condition, completeness of mounting hardware, documentation requirements and whether the frame is supplied separately or as part of the Baklan radio station set.

Product Type: Aircraft shock-mount frame
Designation: IZH6.122.534
Alternative Designations: ИЖ6.122.534, Block 5, Baklan shock-mount frame, Baklan-20 mounting frame
Related Designation: IZH6.122.532, where applicable by configuration
Function: Mechanical mounting and vibration isolation of radio station equipment
Purpose: Protection of the Baklan radio transceiver from vibration and shock loads
Application / Where Used: Aircraft and helicopter VHF radio communication systems
Associated Systems: Baklan-20, Baklan-20D, Baklan-5 and related Baklan-family VHF radio stations where applicable
System Role: Structural mounting base of the radio station set
System / Installation Area: Aircraft radio equipment compartment / radio equipment rack
Installed Equipment: Baklan radio station transceiver; low-frequency amplifier where applicable by configuration
Installation Location: Technical compartment, radio equipment compartment or helicopter radio equipment rack according to aircraft documentation
Typical Aircraft Application: Mi-8 / Mi-17 family helicopters, An-family aircraft and other aircraft equipped with compatible Baklan radio stations
Design: Metal frame with damping elements and locking devices
Installation Variant: Single or paired installation depending on aircraft configuration
Approximate Dimensions, Single Frame: 410 × 134 × 125 mm
Condition: As applicable
Technical Documentation: Manufacturer passport, aircraft installation documentation and radio station technical documentation upon request
