flight data recorder
ZBN-1-1
Price on request
flight data recorder
Description
ZBN-1-1 in onboard flight data recording systems
The ZBN-1-1 is a protected onboard flight data recorder designed for recording and preservation of parametric flight information. It is used as part of aircraft and helicopter flight data recording systems, where processed flight parameters must be stored for post-flight analysis, operational control and investigation of aviation incidents. The recorder works together with data acquisition and processing units and is not intended to collect raw sensor data directly without the rest of the recording system.
Flight data preservation by ZBN-1-1
The main task of the ZBN-1-1 is to preserve recorded flight information under severe emergency conditions. The recorder stores processed aircraft parameters on magnetic tape and protects the recorded medium from impact, fire, pressure and other destructive influences. This makes the ZBN-1-1 one of the key elements of the flight data recording chain. If an incident occurs, the recorder is used to recover information about flight conditions, aircraft systems, engine operation and crew or system actions before the event.
ZBN-1-1 in BUR-1-2 and BUR-1-2Zh systems
The ZBN-1-1 is used in onboard recording systems such as BUR-1-2 and BUR-1-2Zh. In this system architecture, the data acquisition unit collects and converts aircraft parameters, while the ZBN-1-1 performs protected recording and storage. The recorder may be installed on helicopters and fixed-wing aircraft depending on the system configuration. Since it is part of a certified recording system, replacement should be checked against the exact recorder version, aircraft wiring, mounting arrangement and recorder system documentation.
Magnetic tape recording in ZBN-1-1
The ZBN-1-1 records information on magnetic tape. Data is written in Harvard serial code format, with recording speed depending on system configuration. The use of magnetic tape means that mechanical condition is important, not only electrical function. Tape transport, internal recording mechanism, tape condition, drive operation and cleanliness can all affect the quality of the stored data. During maintenance or repair, the condition of the internal tape mechanism should be checked together with the recorder housing and connector.
Protection level of the ZBN-1-1 recorder
The ZBN-1-1 is designed to protect recorded information from high mechanical and thermal loads. It is rated for severe impact, fire exposure and pressure equivalent to deep-water immersion. These protections are necessary because the recorder must preserve data after an accident, not only during normal flight. For aircraft maintenance and storage, the protective housing, seals, connectors and mounting condition should be inspected carefully. Any damage to the protective shell may reduce survivability even if the recorder appears electrically functional.
Aircraft application of ZBN-1-1
The ZBN-1-1 is used on aircraft and helicopters equipped with compatible onboard flight data recording systems. It is associated with Mi-8, Mi-26T, Ka-32, Tu-134, Tu-154, Il-76 and other aircraft depending on configuration. In helicopter applications, it may be part of BUR-1-2Zh or similar recording equipment. The exact installation and compatibility should be verified through the aircraft equipment list, recorder system documentation and mounting configuration before procurement or replacement.
ZBN-1-1 replacement by ZBN-1-3 Series 3
In some systems, the ZBN-1-1 may be replaced by the solid-state protected recorder ZBN-1-3 Series 3, where this replacement is approved by the aircraft documentation. This point is important when preparing a quotation or checking customer requirements. ZBN-1-1 and ZBN-1-3 Series 3 should not be treated as identical units without verification. The recorder interface, mounting, documentation, recording system version and aircraft approval should be checked before confirming interchangeability.
Supply and inspection of ZBN-1-1
For procurement or replacement, the full designation ZBN-1-1 / ЗБН-1-1 should be specified. It is also important to confirm whether the customer needs the complete protected recorder, an internal mechanism, repair service or a replacement recorder such as ZBN-1-3 Series 3. Before installation, the unit should be checked for housing condition, connector integrity, markings, sealing, mounting compatibility, recording function and documentation. For aviation use, product passport and operational documentation should be confirmed where available.
Details
Product Type: Protected onboard flight data recorder
Designation: ZBN-1-1
Alternative Designation: ЗБН-1-1
Function: Recording and preservation of flight parameter data
Application / Where Used: Aircraft and helicopter flight data recording systems
System / Installation Area: Onboard flight data recorder system
Part of System / Included in Set: BUR-1-2, BUR-1-2Zh
Interchangeability / Replaceability: May be replaced by solid-state recorder ZBN-1-3 Series 3 where approved by aircraft documentation
Compatible Aircraft / Equipment: Mi-8, Mi-26T, Ka-32, Tu-134, Tu-154, Il-76 and other aircraft depending on configuration
Recording Medium: Magnetic tape
Recording Data Format: Harvard serial code
Recording Speed: 64 to 1024 words/s
Continuous Recording Duration: Up to 25 h at 512 words/s; up to 22 h at 1024 words/s
Operating Voltage: 27 V DC / 18 to 31 V DC
Power Consumption: Up to 70 W with heating; up to 40 W without heating
Impact Resistance: Up to 3400 g
Fire Resistance: 1100 °C for 30 min; 260 °C for 10 h
Pressure Resistance: Equivalent to 6000 m depth
System Role: Protected storage of recorded parametric flight information
Internal Recording Assembly: Magnetic tape transport / recording mechanism depending on recorder configuration
Weight: Not more than 10.7 kg
Condition: As applicable
Technical Documentation: Product passport and operational documentation
