B7B-PrK

B7B-PrK control panel in the Prima-KV radio station

The B7B-PrK is a cockpit control and indication panel used with the Prima-KV airborne HF / decameter-band radio station. Through this panel, the crew selects operating frequencies, memory channels and communication modes without direct access to the transceiver block. In the aircraft installation, the B7B-PrK is the part of the radio station that the pilots actually use during flight. The main radio blocks may be placed in the avionics bay or equipment rack, while the control panel remains in the cockpit within reach of the crew.

Crew control of Prima-KV through B7B-PrK

The B7B-PrK allows remote operation of the Prima-KV station from the cockpit. The crew can select prepared channels, set the required frequency, choose the emission mode and control the radio station according to the communication task. This is especially important for HF communication, where the station may be used on different assigned frequencies depending on route, region, operator procedures or communication schedule. The panel reduces the need for direct technical access to the radio equipment and keeps communication control in the normal pilot working area.

B7B-PrK channel and frequency selection

The control panel works with the frequency range of the Prima-KV radio station and supports operation with programmable memory channels. In standard use, the required communication channels can be prepared in advance, and the crew can switch between them from the front panel. This is more convenient than entering every frequency manually during flight. The B7B-PrK is therefore not only a set of switches; it is the operator interface for the complete radio system, transferring the selected frequency, channel number and operating mode to the transceiver.

Red cockpit lighting of the B7B-PrK panel

The “B” version of the B7B-PrK is associated with red illumination of the front-panel markings and control elements. This matters in cockpit installations where lighting color must match the aircraft’s night-vision and instrument-lighting requirements. Red illumination is commonly used to preserve visibility in low-light conditions and reduce distraction during night operation. A similar control panel may exist with another lighting color, so the exact designation should be checked carefully before supply. For replacement, B7B-PrK should not be confused with green-light versions if the cockpit standard requires red lighting.

B7B-PrK connection with the B1-PrK transceiver

The B7B-PrK works as a remote digital control terminal for the B1-PrK transceiver unit. It is connected to the radio station by an aircraft wiring harness and exchanges commands with the main radio block. Depending on the version of the Prima-KV station, control data may be transmitted through aircraft digital interfaces or internal serial communication lines. The panel also receives power, lighting supply and control signals through the inter-block wiring. Because of this, a fault in the panel, harness or transceiver input circuit can look like a radio control failure.

Indication and built-in control functions of B7B-PrK

The B7B-PrK is used not only for frequency and mode selection, but also for displaying operating information and supporting built-in test functions. The panel can indicate the selected channel, operating state and service information depending on the exact version and system configuration. Built-in control logic may provide a serviceability indication or fault code display for troubleshooting. In maintenance, this is useful because it helps separate a panel issue from a transceiver, antenna matching unit, power supply or wiring problem.

Installation and supply of B7B-PrK

On Mi-8 / Mi-17 family helicopters, the B7B-PrK can be installed on the central cockpit console, upper electrical panel or other approved communication control panel area depending on the aircraft modification. On fixed-wing aircraft, it may be mounted in the radio control console or avionics control panel. For procurement, the exact panel designation, illumination color, compatibility with the installed Prima-KV version and connector configuration must be checked. The unit may be supplied as a separate aircraft technical item or as part of a complete Prima-KV radio station set.

Product Type: Remote control and indication panel
Designation: B7B-PrK
Radio Station: Prima-KV
Function: Remote control of HF radio station modes, frequency selection and channel selection
Application / Where Used: Aircraft HF / decameter-band communication systems
System / Installation Area: Cockpit radio control panel, central console, upper electrical panel or communication control area depending on aircraft type
Compatible Aircraft / Equipment: Prima-KV installations on Mi-8, Mi-17, Mi-8AMT, Mi-8MTV, Mi-171 and other aircraft depending on approved configuration
Associated Transceiver: B1-PrK / B1A-PrK / B1B-PrK depending on radio station version
Associated Radio Blocks: B5A1-PrK antenna matching unit; PrK / B10A-PrK mounting frame; other Prima-KV installation equipment depending on configuration
Controlled Frequency Range: 2.0000–29.9999 MHz
Frequency Step of Associated Radio Station: 100 Hz
Programmable Channels: Up to 40 channels for standard Prima-KV configuration
Controlled Emission Classes: J3E, H3E / A3E, R3E, F1B, G1B depending on radio station version
Power Supply: 27 V DC aircraft network, supplied according to the aircraft wiring diagram
Panel Illumination: Red illumination of markings and control elements
Illumination Version: “B” version
Control / Data Exchange: Digital or serial inter-block control lines depending on Prima-KV version
Possible Interfaces of Associated System: GOST 18977-79 / ARINC 429, RS-422, RS-232 or internal serial interface depending on system modification
PTT / Transmit Control: Connected with aircraft transmit-command circuits depending on wiring configuration
Built-In Test: Serviceability indication / fault code indication depending on version and configuration
Cooling: Natural, no forced airflow required
Supply Category: Aircraft technical item for installation, modernization, repair or replacement of Prima-KV radio equipment
Technical Documentation: Product passport, Prima-KV operating documentation, aircraft installation documentation and wiring documentation as applicable
