BUR-LKV-01
Onboard flight data
Description
BUR-LKV-01 flight information recording system
BUR-LKV-01 is an onboard system for collecting, processing and recording parametric, voice and audio information. The recorded data is used to investigate aviation incidents, assess the technical condition of aircraft systems and the powerplant, and analyse crew actions during flight. Unlike a single-purpose recorder, BUR-LKV-01 combines several information streams within one recording architecture and preserves them for subsequent operational or investigative analysis.
Full descriptionCollapse description
Information recorded by BUR-LKV-01
The system accepts flight parameters, signals from analog and frequency sources, discrete commands, aircraft identification data, digital-code information and cockpit audio. Its configuration provides separate voice and sound channels and supports prolonged cyclic storage. The exact channel allocation is defined by the aircraft installation and software configuration; therefore the quantities, word format and recording rates stated in Technical Details must be considered together rather than used independently when selecting a replacement.
System composition and data storage
The BUR-LKV-01 installation includes the BUR-LK-01 protected recorder, BS-LK-01 interface unit, PU-SN-10010.2 control panel with removable operational storage and BMi-2 microphone unit. The protected solid-state recorder retains information required for investigation, while the removable storage supports routine flight-data retrieval and operational monitoring. The recorded information can be transferred for processing without treating the individual blocks as interchangeable products.
Aircraft application and operating requirements
BUR-LKV-01 was intended for use as a standard recording system on Ka-226 helicopters and can be adapted for other aircraft types when supported by approved documentation. The system is designed for aviation environmental loads and is associated with ARINC 747, ARINC 717 and ED-112 requirements. The manufacturer also identifies the system as equipment operated according to technical condition. Installation suitability must be confirmed against the aircraft equipment list, wiring data and the exact block configuration.
Identification, documentation and related equipment
Supply should be identified by the complete designation BUR-LKV-01 and by the required composition of the system. Marking, block versions, connectors, storage modules and documentation should be checked before installation. Related catalogue positions include BUR-SL-1 Series 7 and RZBN-1; they are linked for navigation and are not stated to be interchangeable. More equipment is available in the flight recorders and tape devices category. General background on the purpose and operation of this equipment class is available in the flight recorder reference article.
Technical details
- Product Type
- Onboard flight data, voice, and audio recording system
- Function
- Collection, processing, recording, and preservation of flight, voice, and audio information
- Application / Where Used
- Aircraft flight data monitoring and accident investigation systems
- System / Installation Area
- Onboard flight data and voice recording system
- Part of System / Included in Set
- BUR-LK-01 recorder; BS-LK-01 interface unit; PU-SN-10010.2 control panel with removable storage; BMi-2 microphone unit
All specificationsCollapse specifications
- Compatible Aircraft / Equipment
- Ka-226 helicopters; other aircraft types
- Maximum Recording Speed
- 1024 words/s
- Frame Size
- 1024 words
- Word Resolution
- 12 bit
- Number of Analog Input Channels
- 47
- Number of Frequency Signal Channels
- 4
- Number of Discrete Command Channels
- 50
- Aircraft Identification Coding Channels
- 17
- Digital Data Channels (DPK)
- 8
- Number of Voice Channels
- 3
- Number of Audio Channels
- 1
- Voice Recording Duration
- 70 h per channel
- Audio Recording Duration
- 70 h
- Removable Operational Storage
- SN-USB-2
- Power Supply to Potentiometers
- 4 channels
- Potentiometer Supply Current
- 0.075 A per channel
- Standards Compliance
- ARINC 747; ARINC 717; ED-112
- Assigned Resource
- 30,000 flight hours
- Assigned Service Life
- 25 years
- Weight
- 7.5 kg
- Technical Documentation
- Product passport and operational documentation
