GU-10A

Construction and cooling

The design uses vertical mounting, water-cooled anode and forced-air cooling of the bulb and base. These features affect equipment layout and installation requirements: the specified connections and heat removal must be provided for the exact tube execution.

Role in RF equipment

Generator tubes are used where high-frequency power must be generated or amplified. Similar dimensions, a related designation or a comparable cooling method do not establish identical electrical characteristics or interchangeability.

Selection and installation

Before ordering or installing, compare the GU-10A designation, terminal layout, mounting panel, electrode voltages, heater mode and cooling arrangement with the equipment passport. For high-power tubes, the air or water path and electrical-safety provisions are essential parts of the installation.

Information for an enquiry

Water and air cooling are both functional parts of the GU-10A installation, not optional accessories. Confirm tightness of the water circuit, uninterrupted airflow and the required mounting orientation before energising the RF stage.

Please state the exact designation, quantity, marking photograph, required delivery set and equipment details. This permits a compatibility check for the offered execution without assumptions based on similar models.

Working values and limits are taken from the passport for the exact tube. Where that document is unavailable, ratings must not be copied from another version merely because dimensions, cooling method or part of the designation appear similar.
