PSG-15A Series 3
Readiness Indication Panel
Description
PSG-15A Series 3 System Overview
The PSG-15A Series 3 is an aircraft readiness indication panel designed for visual monitoring of system status within onboard electrical systems. The unit is installed in crew workstations and functions as part of aircraft indication and signaling architecture.
Full descriptionCollapse description
PSG-15A Series 3 Indication Function
The panel provides light signaling of system readiness and operational status, enabling the crew to monitor key onboard systems prior to flight and during specific operational procedures. It includes indication elements and control functions for system status verification.
PSG-15A Series 3 Aircraft Application
The unit is used on transport and passenger aircraft, including Il-76 and Tu-154, where it is installed on overhead or flight engineer panels as part of standard cockpit equipment.
PSG-15A Series 3 System Integration
The panel operates as part of onboard signaling systems, interfacing with aircraft systems to display readiness states through light indicators and providing lamp test functionality for system verification. The product is also known under alternative designations PSG-15A Series 3 and ПСГ-15А серия 3.
Technical details
- Product Type
- Readiness indication panel (signaling and control unit)
- Function
- Visual indication of system readiness and status monitoring
- Application / Where Used
- Aircraft onboard signaling and indication systems
- System / Installation Area
- Cockpit overhead panel or flight engineer panel
- Compatible Aircraft / Equipment
- Il-76, Tu-154 and similar aircraft
All specificationsCollapse specifications
- Operating Voltage
- 27 V DC (18–31 V range)
- Current Consumption
- Depends on number of active indicators (approx. 0.04–0.07 A per lamp)
- Type of Indication
- Light signaling panels with text labels (white, green, yellow filters)
- Number of Channels
- Up to 15 indication channels (depending on configuration)
- Control Type
- Push-button control with indication and acknowledgment
- Connector Type
- SH-type or 2RM connectors
- Lamp Type
- SM-28 or equivalent
- Mass
- Approx. 0.8 to 1.5 kg
- Operating Temperature Range
- −60 to +60 °C
- Vibration Resistance
- Suitable for aircraft instrument panel installation
- Altitude Capability
- Up to 20,000–30,000 m
- Design Features (Series 3)
- Improved light readability; integrated lamp test function; increased reliability
- Technical Documentation
- Product passport and operational documentation
