SENSORS
DLUVD-3S
Price on request
SENSORS
Available on back-order
Description
DLUVD-3S is a highly dynamic linear acceleration sensor designed to measure linear accelerations acting along its measuring axis, and to issue an electrical signal in the form of a DC voltage, the value of which is proportional to the linear acceleration acting along the measuring axis, and the sign corresponds to the direction of linear acceleration. The DLUVD-3S sensors are a compensation-type pendulum accelerometer. The principle of operation is based on the property of a physical pendulum to be installed in the direction of the resulting forces acting on it in the direction of the measuring axis.
Details
1. Range of measurement of acceleration – 30 m / s2.
2. Power supply – 15 V ± 1.5 V.
3. Current consumption per amplifier – no more than 0.03 A.
4. The consumed current per set-point is no more than 0.005 A.
5. Ready time – no more than 1 s.
6. Warranty service life of the sensor:
– for objects of short-term action – 300 hours;
– for long-term objects – 3000 hours.
7. The designated shelf life is 11 years.
8. Range of working temperatures – from -60 ° С to + 60 ° С.
9. Weight – no more than 40 g.
