acceleration sensor
DLUMM-50
Price on request
acceleration sensor
Available on back-order
Description
The DLUMM-50 is a microminiature aircraft linear acceleration sensor designed to convert linear accelerations acting along its sensitive axis into a DC electrical voltage signal proportional to the magnitude and direction of acceleration.
Within onboard measurement and recording systems, the sensor provides continuous monitoring of linear accelerations and generates an analog output signal for further processing and registration of flight parameters.
The sensor is used in aviation equipment installed on aircraft as part of onboard measurement and automatic flight parameter recording systems.
The product is also known under alternative designations DLUMM-50, DLUM-50, ДЛУММ-50, ДЛУМ-50, which refer to the same product type.
Details
Product Type: Microminiature linear acceleration sensor
Function: Conversion of linear acceleration into DC voltage signal
Application / Where Used: Aircraft flight parameter measurement and recording systems
System / Installation Area: Onboard measurement and data acquisition systems
Measured Acceleration Range: ±50 g
Operating Voltage: ±12.6 V
Output Voltage: 5 ± 0.28 V
Sensitivity Threshold: not more than 0.1 % of range
Response Readiness Time: 1 s
Operating Temperature Range: −60 to +80 °C
Assigned Service Life: 20 years
Weight: not more than 55 g
Technical Documentation: Product passport / official technical documentation
Payment & delivery
All shipments are carried out from our international warehouse in Dubai (UAE), as well as from our partners’ remote warehouses.
In Stock — items available in stock at the Dubai warehouse are dispatched within 5–10 business days after receiving 100% prepayment.
Remote Stock — items available at our partners’ remote warehouses are supplied within an average of 30–45 business days after receiving 100% prepayment.
Pre-Order — made-to-order products are manufactured and delivered within an average of 45–60 business days. Payment terms: 50% advance payment to start production, with the remaining 50% paid before dispatch from the Dubai warehouse after full readiness for shipment.
Returns & Changes (Restocking Fee)
For selected items, a RESTOCKING FEE of 10% may apply in case of return, order cancellation, or changes to the order specifications. This condition applies only to certain products and is confirmed at the order approval stage.
Warranty
All products are covered by a standard 6-month warranty.
Extended warranty is available upon request and is agreed individually; it may affect the final product price.
