acceleration sensor
DLUMM-3
Price on request
acceleration sensor
Available on back-order
Description
The DLUMM-3 is a microminiature aircraft linear acceleration sensor designed to convert linear acceleration acting along its sensitive axis into a DC electrical voltage signal proportional to the acceleration magnitude and direction.
Within onboard measurement and recording systems, the sensor provides continuous monitoring of linear accelerations, generating an analog output signal used for flight data acquisition, processing, and control functions.
The sensor is applied in aviation equipment installed on fixed-wing aircraft, including transport and passenger aircraft, as part of onboard measurement and flight parameter recording systems.
The product is also known under alternative designations DLUMM-3, DLUMM3, DLUMM 3, DLUM-3, DLUM3, DLUMMз, which refer to the same product type.
Details
Product Type: Microminiature linear acceleration sensor
Function: Conversion of linear acceleration into DC voltage signal
Application / Where Used: Aircraft flight parameter measurement and recording systems
System / Installation Area: Onboard measurement and data acquisition systems
Compatible Aircraft / Equipment: Il-70, Il-76, Yak-42
Measured Acceleration Range: ±3 g
Operating Voltage: ±12.6 ± 1.26 V
Output Voltage: ±5 ± 0.34 V
Zero Signal: not more than ±0.03 V
Sensitivity Threshold: not more than 0.1 % of range
Response Readiness Time: 1 s
Operating Temperature Range: −60 to +80 °C
Assigned Service Life: 20 years
Weight: not more than 55 g
Technical Documentation: Product passport / official technical documentation
