ANGLE SENSOR
15D-60-1
Price on request
ANGLE SENSOR
Available on back-order
Description
15D-60-1 linear induction angle sensor is designed to convert the rotor rotation angle into a proportional linear change in the output voltage amplitude and can be used as a feedback sensor or a linear rotating transformer. Linear induction angle sensors 15D-60-1 are induction electric machines with an implicit-pole stator and a winding-free salient-pole rotor, when rotated from the zero position, the flux linkage of the secondary winding linearly increases to a maximum in a range of angles defined for each type of sensor. Designed for operation in conditions of increased rigidity typical for aircraft products.
Details
1. The outer diameter of the case is 60 mm .;
2. Linearity error – no more than ± 1.5%.
