VS-10-38 1-24h 220v
TIME RELAY
Description
Time relays VS-10-38 1-24h 220v are designed to transfer commands from one electrical circuit to another with certain pre-set time delays. A synchronous electric motor is used as a drive in the relay.
The time delay is created using a special gearbox.
Technical details
1. Supply voltage (AC) 12, 127, 220 V.
2.Lower and upper limits of settings 15 sec – 9 min.
3. Accuracy ±2sec.
4. The minimum interval between adjacent settings is 15 seconds.
5. Return time 0.8 sec.
6. Quantity and type of contacts 3 changeover contacts.
7. Permissible supply voltage variation limit 0.85Unom.
8. Power consumption (DC):
— electric motor 15 VA.
– electromagnet 6 Va.
9. Continuous current of contacts 10 A.
10. The maximum allowable switching frequency, no more than 300 per hour.
11. Mechanical wear resistance 300,000 cycles.
