VL-56 1-100min 24v
TIME RELAY
Description
VL-56 time relays are designed for switching electrical circuits with pre-set time delays and are used in automation circuits. Operating temperature range from -40 to +55°С. Impact of vibrations with acceleration up to 1g. with a frequency of up to 100Hz, up to 2g. with frequency up to 60Hz. Degree of protection relay IP40, terminal clamps - IP00.
Technical details
1. Supply voltage (DC) 24, 110, 220 V.
2. Supply voltage (AC) 110, 220, 230, 240 V.
3. Switched voltage range (DC) 24…220 V.
4. Range of switched voltages (alternating current) 24…380 V.
5. Continuous contact current 4 A.
6. Number of output contacts (switching) – 3.
7. Overall dimensions 120x75x110 mm.
8. Weight, no more than 0.75 kg.
