Description
Time relay programmed daily type RVBM2-2 is designed to automatically turn on and off two consumers of electric current according to independent daily programs. The software time relay is an electromechanical device driven by a clock mechanism and motorized automatic winding. The time relay consists of a molded plastic base on which clock and helical differential mechanisms, a program disk, a synchronous electric motor, a microswitch, a contact group switching mechanism, the contact groups themselves and a terminal block for connecting external wires are installed. From above, all relay elements are closed with a plastic cover, which is held on the base by three screws.
Technical details
1. Relay power supply: 220V 50Hz.
2. Current switched by contacts: 15A AC, 1.5A DC.
3. Rated contact voltage: 220V 50Hz, DC 12-220V.
4. Dimensions: new version 125 x 180 x 170mm (H x W x D).
5. Weight, no more than 1.5 kg.
