Description
RV-2-10 ser 2 time relay is used to obtain an independent time delay. The time relay is used in circuits where it is necessary to automatically perform some action after a certain period of time. The relay mechanism is housed in a plastic case, on the front of the relay there is a switch for the setting sub-range and a time delay setting knob.
Technical details
1. Rated supply voltage – AC – 220 V, DC – 24 + 2 V.
2. Switched voltage – 220 V.
3. Switched current – 5 A.
4. Rated current frequency — 50+1 Hz.
5. The range of setting the time of each channel is from 1 s to 120 min.
6. The number of subbands of each – 7 channels – (1 s – 30 s; 2 s – 60 s; 4 s – 120 s; 0.5 min – 15 min; 1 min – 30 min; 2 min – 60 min; 4 min – 120 minutes).
7. Relay weight – no more than – 0.4 kg.
