RPV2/7 RS4.521.958

1. The supply current of the winding is constant.
2. Insulation resistance between current-carrying elements, between current-carrying elements and the housing:
in normal climatic conditions (the winding is de-energized) – 500 MΩ.
– at maximum temperature (after holding the winding under operating voltage) – 20 MΩ.
in conditions of high humidity:
– between contacts, between contacts and case – 10 MΩ.
– between the windings and the case – 5 MΩ.
3. Test alternating voltage between current-carrying elements, between current-carrying elements and the case:
– in normal climatic conditions – 500 V.
– in conditions of high humidity – 300 V.
– at reduced atmospheric pressure – 180 V.
4. Electric capacity:
– between open contacts, taking into account the capacitance between the contacts and the case – 1 pF.
– between open contacts with the exception of the capacitance between the contacts and the housing (through capacitance), no more than – 0.1 pF.
— between contacts and case, no more — 2 pF.
5. Attenuation in the circuit of closed contacts with a switched power from 1 to 24 W is not more than 2% of the transmitted power.
6. Relay weight no more than 20 g.
