RPS55 RS4.569.906-14
RELAYS ELECTROMAGNETIC LOW-CURRENT
Description
Relays RRPS55 RS4.569.906-14 dust and splash proof, reed switch, polarized, designed for switching DC and AC electrical circuits with a frequency of up to 100 kHz.
Technical details
1. The supply current of the winding is constant.
2. Insulation resistance between current-carrying elements, between current-carrying elements and the case, not less than:
– in normal climatic conditions (windings are de-energized) – 1000 MΩ.
– at maximum temperature (after holding the winding under operating voltage) – 80 MΩ.
– in conditions of high humidity – 5 MΩ.
3. Test alternating voltage between current-carrying elements, between current-carrying elements and the case:
– in normal climatic conditions – 500 V.
– in conditions of high humidity – 300 V.
– at reduced atmospheric pressure – 500 V.
4. Electrical contact resistance is not more than 0.25 Ohm.
5. Relay weight – 80 g.
