RPG-3K 2302-U3 12V
RELAYS ELECTROMAGNETIC LOW-CURRENT
Description
Intermediate reed relay RPG-3K 2302-U3 12V is used in automation and control circuits with power supplies for voltages of 12 and 24V DC or rectified three-phase current with a ripple frequency of at least 300 Hz without the use of a filter or rectified with a filter that provides a ripple of no more than 6% .
The relays are suitable for operation in control systems based on microprocessor technology and are components.
Technical details
1. Rated supply voltage 12 and 24 V;
2. Deviation of the supply voltage of the control coil 0.85-1.1 Unom;
3. Rated current of relay contacts 1.25 A;
4. Rated operating currents of contacts 5 * 10-6-1.25 A;
5. Rated voltage of relay contacts 127 V;
6. Rated operating voltage of contacts 5*10-2-127 V;
7. Mechanical wear resistance of contacts of VO cycles, not less than 1 million;
8. Electrical strength of insulation in normal climatic conditions 1000 V.
