RP7 RS4.521.000
RELAYS ELECTROMAGNETIC LOW-CURRENT
Description
Relays RP7 RS4.521.000 sheathed, polarized, with one switching element, designed for switching DC electrical circuits.
Technical details
1. The supply current of the windings is constant (pulse).
2. Insulation resistance between current-carrying elements, between current-carrying elements and the case, not less than:
– in normal climatic conditions – 100 MΩ.
– in conditions of high humidity – 5 MΩ.
– at maximum temperature (windings under current) – 100 MΩ.
3. Test alternating voltage:
– in normal climatic conditions:
– between current-carrying elements and the case – 350 V.
– between contacts – 250 V.
– between the windings – 110 V.
– in conditions of high humidity:
– between current-carrying elements and the case – 210 V.
– between contacts – 150 V.
– between the windings – 70 V.
4. The resistance of the electrical contact is not more than 1.5 ohms.
5. Relay weight no more than 220 g.
