REV16 RF4.562.009-00.02
RELAYS ELECTROMAGNETIC LOW-CURRENT
Description
Relays REV16 RF4.562.009-00.02 non-sealed, high-frequency, coaxial, neutral, two-position, single-stable, with one changeover contact, designed for switching high-frequency signals with a frequency of up to 1000 MHz when operating in coaxial paths.
Technical details
1. Dielectric strength of insulation between current-carrying circuits: 50 V.
2. Dielectric strength of insulation between current-carrying circuits and case: 500 V.
3. Vibration loads:
– frequency range 2500 Hz.
— acceleration 100 (10) m/s2 (g).
4. Linear acceleration: 250 (25) m/s2 (g).
5. Mechanical impact, single action with acceleration: 1000 (9) m/s2 (impacts).
6. Mechanical impact, multiple action with acceleration: 350 (10000) m/s2 (impacts).
7. Relative air humidity at +35°C: up to 98%.
8. Atmospheric pressure: from 666 to 2.03×105 Pa.
Ambient operating temperature: -60 to +100 °C.
9. Relay weight: 140.0 g.
10. Minimum service life: 12 years.
