RES93 YAL4.500.014
RELAYS ELECTROMAGNETIC LOW-CURRENT
Description
Electromagnetic reed relay RES93 YAL4.500.014 DC with two closing contacts. Designed for switching electrical circuits of direct and alternating current with a frequency of up to 10,000 Hz.
Technical details
1. Linear acceleration: up to 1000 (100) m/s2 (g).
2. Mechanical impact, single action with acceleration: 1500 (9) m/s2 (impacts).
3. Mechanical impact, multiple action with acceleration: 750 (4000) m/s2 (impacts).
4. Relative humidity at +35°C: up to 98%.
5. Atmospheric pressure: from 1.33×10-6 to 3.04×105 Pa.
6. Operating ambient temperature: -60 to +85 °C.
7. Relay Weight: 2.8g
8. Minimum service life: 12 years.
