RES90 YAL4.550.000-31
RELAYS ELECTROMAGNETIC LOW-CURRENT
Description
Relay RES90 YAL4.550.000-31 is sealed, single-stable, two-position, with two changeover contacts. Designed for switching electrical circuits of direct and alternating current with a frequency of up to 10,000 Hz.
Technical details
1. Electrical strength of insulation between current-carrying elements: 500 V.
2. Dielectric strength of insulation between current-carrying elements and case: 500 V.
3. Linear acceleration: up to 5000 (500) m/s2 (g).
4. Mechanical impact, single action with acceleration: 5000 (9) m/s2 (impacts).
5. Mechanical impact, multiple action with acceleration: 1500 (4000) m/s2 (impacts).
6. Relative air humidity at +35°C: up to 98%.
7. Atmospheric pressure: from 1.33×10-6 to 2.97×105 Pa.
Ambient operating temperature: -60 to +125 °C.
8. Relay weight: 16.5 (19.5) g.
9. Minimum service life: 12 (20) years.
