RES44 RS4.569.253
RELAYS ELECTROMAGNETIC LOW-CURRENT
Description
Relays RES44 RS4.569.253 are reed, two-position, single-stable, designed for switching electrical circuits of direct and alternating current with a frequency of up to 10 kHz.
Technical details
1. Winding supply current – constant;
2. Winding resistance A-B 3040-4560 Ohm;
3. Winding actuation voltage 22 A-B;
4. The release voltage of the winding A-B 2 V;
5. The operating voltage of the winding A-B 43-53 V;
6. Test alternating voltage:
– in normal climatic conditions:
– between current-carrying elements and the housing, between magnetically controlled contacts, between contacts and windings 500 V;
– between windings 300 V;
– between the terminals of each magnetically controlled contact 200 V;
– in conditions of high humidity:
– between current-carrying elements and the housing, between magnetically controlled contacts, between contacts and windings, between windings 300 V;
– between the terminals of each magnetically controlled contact 200 V;
– at reduced atmospheric pressure between current-carrying elements, between current-carrying elements and the housing 180 V;
7. Time of continuous or total operation of the relay at normal atmospheric pressure and maximum ambient temperature 100 hours;
8. Electrical contact resistance 0.2 ohm;
9. Relay weight, no more than 18 g.
