RES10 RS4.529.031-11.02
RELAYS ELECTROMAGNETIC LOW-CURRENT
Description
RES10 RS4.529.031-11.02 non-hermetic, two-position, one-stable DC relay with changeover and normally open contacts, designed for switching DC and AC circuits with a frequency of 50 ... 1100 Hz.
Technical details
1. Linear acceleration: up to 250 (25) m/s2 (g).
2. Mechanical impact, single action with acceleration: 1000 (100) m/s2 (g).
3. Mechanical shock, multiple action with acceleration: 300 (9) m/s2 (g).
4. Relative humidity at +35°C: up to 98%.
5. Atmospheric pressure: from 6.65×102 to 10.64×104 Pa.
6. Operating ambient temperature: -60 to +70 °C.
7. Relay Weight: 7.5g
8. Minimum service life: 12 years.
