SG-18-1S
starter-generator
Description
The SG-18-1S is a DC starter-generator with mixed excitation and forced air cooling, designed for electric starting of diesel engines, onboard power supply, and battery charging.
Within the power supply system, the unit operates in two modes, functioning as a starter during engine start and as a generator after engine start to supply electrical consumers and maintain battery charge.
The starter-generator is applied in engine-driven onboard electrical systems of aircraft and ground equipment equipped with DC power networks.
The product is also known under alternative designations СГ-18-1С, SG18-1S, which refer to the same product type.
Technical details
- Product Type
- DC starter-generator
- Function
- Engine starting, onboard power generation, battery charging
- Application / Where Used
- Aircraft onboard electrical systems
- System / Installation Area
- Powerplant electrical equipment
- Operating Voltage
- 28.5 V
All specificationsCollapse specifications
- Nominal Power
- 18 kW
- Armature Speed (Nominal)
- 3600–6200 rpm
- Operating Mode
- Continuous (generator), intermittent (starter)
- Overload Capability
- Up to 800 A for 1 min with 30 min interval
- Insulation Resistance (Heated)
- 1.5 MΩ
- Direction of Rotation
- Clockwise (viewed from drive side)
- Cooling Method
- Air cooling
- Construction Execution
- Dust and splash protected, single-wire, shielded
- Dimensions
- Diameter 250 mm; length 600 mm
- Weight
- Not more than 78 kg
- Welding Mode (Open-Circuit Voltage)
- 60 V
- Welding Current Range
- 10–300 A
- Duty Cycle (Welding)
- 40%
- Technical Documentation
- Product passport SG-18-1S
