GSR-18000M
DC Generator
Description
GSR-18000M high-output DC generator
GSR-18000M is an 18 kW engine-driven DC generator intended to feed an aircraft primary electrical network. Technical and aircraft-system references identify it as a high-current generator mounted on the engine. Published values consistently indicate a 28.5 V system and an output class of approximately 600 A; the exact series and nameplate remain controlling for installation.
Full descriptionCollapse description
Documented aircraft and engine applications
GSR-18000M is documented on the Tupolev Tu-95 family, where eight generators—two per engine—feed the primary DC buses in parallel with 12SAM-55 batteries as emergency sources. A Tupolev Tu-128 description lists one generator per engine working in parallel with 12SAM-23 batteries. Two units are also documented on each RD-3M-500 engine installation.
Electrical-system context
The generator supplies the main DC network; it is not the same device as the SGO-series AC generators or PO/PT rotary converters used elsewhere in the same aircraft. On Tu-95 descriptions, SGO-30U machines supply variable-frequency AC while PO-4500 and PT-series converters support stable-frequency loads. This separation matters when identifying the required unit and selecting cross-system equipment.
Brush gear and inspection
Published brush catalogues associate GSR-18000M with MGS-7i carbon brushes, a 4 × 20 × 26.5 mm block arrangement, three pieces per group and eight groups in the machine. Incoming inspection should verify the exact brush drawing, collector condition, bearings, drive end, cooling passages, high-current terminals and insulation. Brush data help identify service parts but do not replace the generator passport.
Selection and ordering GSR-18000M
Reference data list a mass of approximately 41.5 kg for an engine-mounted GSR-18000M. Speed, rotation, drive coupling and cooling requirements should be taken from the exact series manual and aircraft installation data. A related 555.143 brush card is available for component-level review; catalogue links do not declare interchangeability or serviceability.
Technical details
- Product Type
- High-output engine-driven DC generator
- Part Number
- GSR-18000M
- Original Cyrillic Designation
- ГСР-18000М
- Electrical Output
- Direct current
- Nominal Power
- 18 kW
All specificationsCollapse specifications
- Nominal Voltage
- 28.5 V DC
- Published Current Class
- Approximately 600 A; verify the exact series passport
- Installation
- Engine-mounted in documented aircraft applications
- Published Mass
- Approximately 41.5 kg
- Documented Aircraft 1
- Tupolev Tu-95 family
- Tu-95 Installation
- Eight generators; two per engine in the documented system
- Tu-95 Battery Context
- 12SAM-55 batteries as emergency DC sources
- Documented Aircraft 2
- Tupolev Tu-128
- Tu-128 Installation
- One generator per engine; parallel operation on a common network
- Tu-128 Battery Context
- 12SAM-23 batteries in the documented system
- Documented Engine Context
- RD-3M-500; two generators per engine installation
- Brush Grade
- MGS-7i in published brush catalogues
- Brush Block Data
- 4 × 20 × 26.5 mm arrangement for the documented GSR-18000M entry
- Brush Grouping
- 3 pieces per group; 8 groups in the documented entry
- Operating Speed
- Confirm from the exact series passport
- Rotation and Drive
- Confirm from the engine installation manual and nameplate
- Cooling
- Confirm from the exact aircraft and generator documentation
- Compatibility Check
- Verify series, nameplate, drive, rotation, mounting, terminals, cooling and protection
