GSR-12KIS
DC Generator
Description
GSR-12KIS high-output DC generator
GSR-12KIS is a 12 kW aircraft DC generator intended for a stabilized 28.5 V onboard network. Published aircraft descriptions document one generator on each R15BD-300 engine of reconnaissance versions of the MiG-25. The KIS suffix is part of the exact designation and must be retained when checking the engine drive and electrical channel.
Full descriptionCollapse description
Electrical output and speed range
The consistently published ratings are 12 kW, 28.5 V DC and an operating-speed range of approximately 4,000–9,000 rpm. Reference tables differ on nominal current, listing 400 A or about 420 A; a 450 A value is associated with a BK-2S execution in commercial data. The base GSR-12KIS card therefore records the source difference instead of presenting 450 A as universally valid.
Combined cooling at high flight speed
Technical training material describes combined evaporative cooling. Air cooling is used below approximately Mach 1.5; above that regime an alcohol-water mixture is supplied to the generator cooling jacket. The documented mixture is 50/50, with total coolant consumption about 13 ± 1 l/h and water consumption about 5–5.5 l/h. The cooling circuit and aircraft limits must be serviceable before generator operation.
Short-time overload and installation
The reviewed material records 630 A for up to one minute at 5,500–8,000 rpm and 840 A for up to ten seconds at 8,000 rpm. These are short-time limits, not continuous ratings. Installation checks include the engine drive, mounting, rotation, high-current terminals, insulation, collector and brush gear, cooling connections and the correct regulator and protection devices.
Identification and ordering GSR-12KIS
Published mass figures vary substantially between base and suffixed executions, so the individual passport and nameplate control the delivered configuration. Do not use dimensions or mass from GSR-12KIS-BK or BK-2S as values for the base unit without confirmation. Related machines are listed under Generators & Starter-Generators; cross-sells provide navigation only.
Technical details
- Product Type
- High-output aircraft DC generator
- Part Number
- GSR-12KIS
- Original Cyrillic Designation
- ГСР-12КИС
- Nominal Power
- 12 kW
- Nominal Voltage
- 28.5 V DC
All specificationsCollapse specifications
- Published Nominal Current
- 400–420 A in base reference tables; verify the individual passport
- Operating Speed
- Approximately 4,000–9,000 rpm
- Documented Aircraft Context
- MiG-25 reconnaissance versions
- Documented Engine Context
- R15BD-300; one generator per engine in the reviewed description
- Cooling Type
- Combined air and evaporative liquid cooling
- Air-Cooling Regime
- Below approximately Mach 1.5 in the reviewed material
- Liquid-Cooling Regime
- Above approximately Mach 1.5 in the reviewed material
- Coolant
- 50/50 alcohol-water mixture in the documented system
- Total Coolant Consumption
- Approximately 13 ± 1 l/h
- Water Consumption
- Approximately 5–5.5 l/h
- Short-Time Overload 1
- 630 A for up to 1 minute at 5,500–8,000 rpm
- Short-Time Overload 2
- 840 A for up to 10 seconds at 8,000 rpm
- Continuous 450 A Rating
- Not assigned to the base card; published for a BK-2S execution
- Dimensions and Mass
- Source-dependent by execution; confirm from the individual passport
- Compatibility Check
- Verify suffix, engine drive, rotation, terminals, cooling circuit, regulation and protection
