LUN 1107-8

LUN 1107-8 dual-scale aircraft airspeed indicator LUN 1107-8

LUN 1107-8 is the exact Part Number for this LUN LUN 1107-8 dual-scale aircraft airspeed indicator. The unit provides cockpit airspeed indication on its marked 0–200 and 0–400 km/h scales in a compatible aircraft installation. This card is tied to the photographed configuration and complete suffix, rather than serving as a generic listing for every LUN 1107-8 version or a visually similar member of the same family.

The source inventory identifies the exact designation LUN 1107-8, serviceable condition, EASA Form 1 and serial number 3427. The photographed face also shows the LUN 1107-8 designation and serial number 3427. Exact accuracy, pressure calibration, environmental, dimensional and mass values were not confirmed in reliable open documentation for this exact version. The identification information is important because voltage, lighting, software, hardware options, certification and connector configuration can differ across related versions. The complete Part Number and the approved technical record must be checked together before purchase or installation.

Operational role and system function

The source listing identifies LUN 1107-8 as a speedmeter with a 0–400 km/h range, while the photographed face also carries a second 0–200 scale. It is a cockpit indication instrument whose performance depends on the approved pressure connections, panel installation and aircraft pitot-static system. The source record does not identify a specific aircraft type for this exact suffix. In service, the unit depends on the integrity of its associated sensors, antennas, transceivers, control panels, displays, data buses, wiring, power and grounding. A reported fault at the unit can therefore originate elsewhere in the connected chain, and troubleshooting should follow the approved aircraft and equipment procedures.

The practical role of LUN 1107-8 is to perform its defined function while exchanging required signals with compatible equipment. It cannot replace missing system components and should not be evaluated as an isolated consumer device. Controls or connectors visible in photographs do not prove that every possible function is enabled in a particular aircraft installation.

Installation and connected equipment

The instrument must be installed and tested according to the aircraft and manufacturer documentation, including the applicable pressure line, panel mounting and any lighting or electrical connections present in the exact configuration. The pitot-static system and all pressure connections require approved leak checks and functional verification before return to service. A rack, backplate, connector kit, antenna, wiring, cooling hardware or other accessories are not assumed to be included unless they are expressly listed in the quotation. Similar panel dimensions or family names do not prove electrical or approval compatibility.

Before installation, technicians should compare LUN 1107-8 with the removed unit, aircraft equipment list, wiring diagrams, installation manual and modification records. Panel space, mounting depth, connector keying, pin allocation, circuit protection, lighting, ventilation, data format and configuration settings all require confirmation. Any substitution must be supported by approved data.

Configuration checks for LUN 1107-8

The suffix in LUN 1107-8 is part of the product identity. Software level, modification status, database requirements, embedded options, voltage and certification can affect compatibility even when two units look alike. These checks are especially important in aircraft that have accumulated supplemental approvals, avionics upgrades or wiring changes over time.

Incoming inspection should verify the manufacturer plate, housing, connectors, locking features, controls, display or indicator face, fasteners and evidence of unauthorized modification. Functional testing should use the approved bench procedure for the exact model and suffix. Installation and return to service remain the responsibility of appropriately authorized personnel.

Serviceable condition, ordering and support

This LUN 1107-8 LUN 1107-8 is offered in Serviceable condition from partner stock with a six-month warranty. Partner stock should be reconfirmed at quotation because allocation can change. The available serial number, current test status and release documentation for the specific unit are confirmed before order acceptance.

For an inquiry, specify Part Number LUN 1107-8, model LUN 1107-8, required quantity, destination and documentation requirements. Including the aircraft type and removed-unit Part Number helps prevent configuration errors. Related avionics can be reviewed in the Garmin / BendixKing / Honeywell / Collins category. Products shown there are related catalog positions, not interchangeable replacements unless approved technical data explicitly says so.

Product Type: Dual-scale aircraft airspeed indicator

Designation: LUN 1107-8

Manufacturer: LUN

Model: LUN 1107-8

Function: Cockpit airspeed indication in a compatible pitot-static instrument installation

Outer Scale: 0–200 km/h as shown on the photographed face

Inner Scale: 0–400 km/h as shown on the photographed face and stated in the source listing

System: Aircraft pitot-static instrumentation; exact aircraft application not confirmed in the source listing

Serial Number: 3427 on the photographed instrument and in the source inventory

Unconfirmed Specifications: Exact pressure calibration, accuracy, lighting supply, dimensions, weight and connection details were not confirmed in reliable open documentation for this exact suffix

Condition: Serviceable

Warranty: 6 Months

Installation Note: Confirm the exact Part Number, suffix, software or modification status, rack, connectors, wiring and aircraft approval before installation

Technical Documentation: Applicable manufacturer installation and maintenance data plus aircraft wiring and approval documentation

All shipments are carried out from our international warehouse in Dubai (UAE), as well as from our partners’ remote warehouses.

In Stock — items available in stock at the Dubai warehouse are dispatched within 5–10 business days after receiving 100% prepayment.

Remote Stock — items available at our partners’ remote warehouses are supplied within an average of 30–45 business days after receiving 100% prepayment.

Pre-Order — made-to-order products are manufactured and delivered within an average of 45–60 business days. Payment terms: 50% advance payment to start production, with the remaining 50% paid before dispatch from the Dubai warehouse after full readiness for shipment.

Returns & Changes (Restocking Fee)
For selected items, a RESTOCKING FEE of 10% may apply in case of return, order cancellation, or changes to the order specifications. This condition applies only to certain products and is confirmed at the order approval stage.

Warranty
All products are covered by a standard 6-month warranty.
Extended warranty is available upon request and is agreed individually; it may affect the final product price.
