5934PM-3

5934PM-3 three-pointer pressure altimeter

The United Instruments 5934PM-3 is a three-pointer pressure altimeter. The unit indicates barometric altitude from the aircraft static-pressure system on a mechanical three-pointer display. This card is based on the exact partner inventory record and the complete designation shown above; it is not a generic listing for every visually similar version in the same equipment family.

The APN inventory record identifies 5934PM-3 in serviceable condition. Its listing images show 5934PAM-3 and were therefore rejected. The replacement catalog image is an exact-model 5934PM-3 reference image, and the technical values are limited to the documented 20,000-foot millibar configuration. The source condition is Serviceable. Technical statements in this listing are limited to the exact functions and characteristics documented for this position. Unknown dimensions, current consumption, pin assignments or aircraft applicability are not inferred from a related model.

Operational role and system function

The 5934PM-3 is a non-encoding cockpit altimeter. Its millibar setting scale allows the crew to set the applicable reference pressure, while the pointer mechanism displays altitude in feet. It does not independently supply encoded altitude data to a transponder. In normal service, correct operation also depends on the associated antennas, sensors, control heads, displays, power, grounding and wiring that belong to the approved aircraft installation. A fault indication at one component does not by itself prove that the component is the source of the system fault.

The equipment must be evaluated as part of its complete signal chain. Controls, connectors or labels visible in a photograph confirm physical features of the photographed configuration, but they do not prove that optional functions, software features or approvals are enabled in a particular aircraft. Approved technical data remains the controlling reference.

Installation and connected equipment

Installation requires an approved static-pressure connection, a suitable 3-inch instrument-panel opening and the mounting hardware defined by the applicable aircraft data. The instrument must be leak-tested and calibrated after installation. A rack, backplate, connector kit, antenna, coupler, wiring harness or other installation hardware is not assumed to be included unless it is explicitly named in the quotation or Delivery Set.

Before installation, technicians should compare 5934PM-3 with the removed unit, aircraft equipment list, wiring diagram, modification status and applicable manufacturer manual. Panel dimensions, mounting depth, connector keying, pin allocation, circuit protection, lighting, cooling, data format and configuration settings all require confirmation. Similar appearance is not evidence of interchangeability.

Configuration checks for 5934PM-3

The complete designation and suffix are part of the product identity. Hardware revision, modification status, voltage, lighting, software, database, certification and connector configuration can differ between closely related variants. These details should be confirmed against the aircraft records and the specific serial number allocated for supply.

Incoming inspection should verify the manufacturer plate, housing, connectors, locking features, controls, display or indicator face, fasteners and evidence of unauthorized modification. The inspection should also confirm that shipping protection and supplied accessories agree with the quotation. Functional testing should follow the approved bench procedure for the exact model. Installation and return to service remain the responsibility of appropriately authorized personnel.

Serviceable condition, ordering and support

This 5934PM-3 is offered in Serviceable condition from Partner Stock with a six-month warranty. Partner availability can change, so allocation, the available serial number, current test status and release documentation are reconfirmed before order acceptance. Image processing does not alter or upgrade the declared commercial condition.

For an inquiry, specify 5934PM-3, model 5934PM-3, quantity, destination and documentation requirements. Adding the aircraft type, removed-unit Part Number and installation details helps prevent configuration errors. Buyers may also request current photographs of the allocated serial number and clarification of the quoted delivery set before confirming the order. Packaging and transport arrangements are selected for the destination and the physical characteristics of the unit.

Related avionics are available in the Garmin / BendixKing / Honeywell / Collins category. Cross-sell products are related catalog positions, not interchangeable replacements unless approved data explicitly confirms substitution.

Product Type: Three-pointer pressure altimeter

Designation: 5934PM-3

Manufacturer: United Instruments

Model: 5934PM-3

Function: Indicates barometric altitude from the aircraft static-pressure system on a mechanical three-pointer display

Altitude Range: −1,000 to +20,000 ft

Barometric Scale: Millibars

Pointer Configuration: Three-pointer mechanical indication

Configuration Reference: 5934PM-3A.84 in the United Instruments specification table

Static Pressure Connection: 1/8-27 ANPT for the A.84 configuration

Typical Weight: 13 oz / 0.37 kg for the A.84 configuration

Certification Reference: FAA TSO-C10b for the documented product family

Partner Inventory Serial Reference: 506975

Condition: Serviceable

Warranty: 6 Months

Installation Note: Confirm exact designation, suffix, serial allocation, rack, connectors, wiring, configuration and aircraft approval before installation

Technical Documentation: Applicable manufacturer installation and maintenance data plus aircraft wiring and approval documentation
