069-01033-0101

KX 165A VHF NAV/COM transceiver — 069-01033-0101

069-01033-0101 identifies this BendixKing / Honeywell KX 165A VHF NAV/COM transceiver. The unit provides aircraft VHF communication and VOR/localizer/glideslope navigation functions. This card is based on the exact partner inventory record and the complete designation shown above; it is not a generic listing for every visually similar version in the same equipment family.

The partner source describes the item as: 25 kHz channel spacing – 760 Channels 28 Volts HSI Output (Left/Right/GS/Flags) King Serial Output for RMI 10 Watts power output FM immune compliant for ICAO Annex 10 TSO’d. The source condition is Repaired. Technical statements in this listing are limited to the exact functions and characteristics documented for this position. Unknown dimensions, current consumption, pin assignments or aircraft applicability are not inferred from a related model.

Operational role and system function

KX 165A combines a communication transceiver and navigation receiver in a panel-mounted unit. It can supply left/right, glideslope and flag information to a compatible HSI and King serial data to a compatible RMI. In normal service, correct operation also depends on the associated antennas, sensors, control heads, displays, power, grounding and wiring that belong to the approved aircraft installation. A fault indication at one component does not by itself prove that the component is the source of the system fault.

The equipment must be evaluated as part of its complete signal chain. Controls, connectors or labels visible in a photograph confirm physical features of the photographed configuration, but they do not prove that optional functions, software features or approvals are enabled in a particular aircraft. Approved technical data remains the controlling reference.

Installation and connected equipment

Installation requires COM and NAV antennas and coaxial cables, audio-system wiring, 28 V power, rack and connectors, plus approved HSI, CDI or RMI interfaces where used. A rack, backplate, connector kit, antenna, coupler, wiring harness or other installation hardware is not assumed to be included unless it is explicitly named in the quotation or Delivery Set.

Before installation, technicians should compare 069-01033-0101 with the removed unit, aircraft equipment list, wiring diagram, modification status and applicable manufacturer manual. Panel dimensions, mounting depth, connector keying, pin allocation, circuit protection, lighting, cooling, data format and configuration settings all require confirmation. Similar appearance is not evidence of interchangeability.

Configuration checks for 069-01033-0101

The complete designation and suffix are part of the product identity. Hardware revision, modification status, voltage, lighting, software, database, certification and connector configuration can differ between closely related variants. These details should be confirmed against the aircraft records and the specific serial number allocated for supply.

Incoming inspection should verify the manufacturer plate, housing, connectors, locking features, controls, display or indicator face, fasteners and evidence of unauthorized modification. The inspection should also confirm that shipping protection and supplied accessories agree with the quotation. Functional testing should follow the approved bench procedure for the exact model. Installation and return to service remain the responsibility of appropriately authorized personnel.

Repaired condition, ordering and support

This 069-01033-0101 KX 165A is offered in Repaired condition from Partner Stock with a six-month warranty. Partner availability can change, so allocation, the available serial number, current test status and release documentation are reconfirmed before order acceptance. Image processing does not alter or upgrade the declared commercial condition.

For an inquiry, specify 069-01033-0101, model KX 165A, quantity, destination and documentation requirements. Adding the aircraft type, removed-unit Part Number and installation details helps prevent configuration errors. Buyers may also request current photographs of the allocated serial number and clarification of the quoted delivery set before confirming the order. Packaging and transport arrangements are selected for the destination and the physical characteristics of the unit.

Related avionics are available in the Garmin / BendixKing / Honeywell / Collins category. Cross-sell products are related catalog positions, not interchangeable replacements unless approved data explicitly confirms substitution.

Product Type: Vhf nav/com transceiver

Designation: 069-01033-0101

Manufacturer: BendixKing / Honeywell

Model: KX 165A

Function: Provides aircraft vhf communication and vor/localizer/glideslope navigation functions

COM Channel Spacing: 25 kHz

Channel Count: 760

Power Supply: 28 V DC

Minimum RF Output: 10 W

HSI Outputs: Left/right, glideslope and flags

RMI Interface: King serial output

Compliance Reference: FM-immune for ICAO Annex 10 according to the source listing

Certification Reference: TSO-approved according to the source listing

Partner Inventory Serial Reference: 2210

Condition: Repaired

Warranty: 6 Months

Installation Note: Confirm exact designation, suffix, serial allocation, rack, connectors, wiring, configuration and aircraft approval before installation

Technical Documentation: Applicable manufacturer installation and maintenance data plus aircraft wiring and approval documentation
