066-1069-02

BendixKing KDI 573 indicator 066-1069-02

066-1069-02 is the inventory Part Number for this BendixKing KDI 573 DME indicator. Manufacturer catalog data also presents the zero-padded form 066-01069-0002 and describes the unit as a slaved DME indicator. The KDI 573 is intended to give a copilot or additional crew position access to DME information within a compatible installation. It is not a complete DME receiver and does not independently interrogate ground stations.

The exact suffix must remain part of the identification. KDI 573 indicators can be visually similar to other members of the KDI 57x family, but their system role, selection controls, lighting, interface and installation approval are not the same. The available reference photograph shows the characteristic KDI 573 face; however, an exact readable -02 identification plate is not visible. The allocated unit must therefore be confirmed by its plate and release record before supply.

Slaved DME display function

In an approved arrangement, the KDI 573 receives compatible display information from a master KDI 572 or KDI 574 installation. It can present distance, groundspeed and time-to-station data for the crew position. Those values originate from the associated DME system. Groundspeed and time are derived from changing slant-range distance and are most useful while the aircraft tracks toward or away from the selected station.

The KDI 573 should be understood as a repeater or slaved indicator rather than a master control head. It does not replace the master selector, remote DME transceiver, antenna or navigation-channel source. Display availability depends on the master indicator, the remote transceiver, valid ground-station replies, wiring and aircraft configuration. A blank or flagged display can therefore require system-level troubleshooting instead of isolated indicator replacement.

System composition and companion equipment

A representative chain is navigation-channel source → KDI 572 or KDI 574 master interface → compatible remote DME transceiver → DME antenna and ground station → processed distance information → KDI 573 slaved display. BendixKing documentation identifies the KDI 573 as usable with KDI 572 or KDI 574 display arrangements. Every combination remains subject to the approved installation and the exact interface requirements.

The adjacent KDI 572, KDI 574 and compatible DME transceiver may be useful related products, but they are not interchangeable with the KDI 573. The KDI 572 is a master display with source selection, the KDI 574 is a master display without that selector arrangement, and the KDI 573 serves the additional display position. Replacing one model with another may require different controls, wiring, lighting or approval and must not be based on bezel dimensions alone.

Exact-configuration checks before installation

Because the available authentic front photograph does not expose the exact -02 plate, no weight, voltage, connector pinout, dimensions, environmental category or serial number has been copied from photographs of -01 or -04 units. Manufacturer catalog identification supports the 066-01069-0002 designation, while all configuration-specific technical values should be verified from approved KDI 573 data and the plate of the allocated item.

Receiving inspection should confirm both forms of the Part Number, model legend, manufacturing year record, display window, bezel, mounting points, rear connector, condition and certification. Functional testing should verify power-up, illumination, display segments, valid data from the master indicator, selected-source response and failure indications. The 2019 year applies to the offered inventory position and should be checked against the serial-numbered documentation delivered with the unit.

New unused supply and ordering information

This KDI 573 inventory position is identified as New / Unused, Year of Manufacturing 2019, and is offered from partner stock with a six-month warranty. The standard website condition attribute is shown as New. The quotation will confirm the allocated serial number, preservation history, release documentation, current test status and any included accessories. New or unused status does not by itself establish eligibility for a particular aircraft.

For an inquiry, specify Part Number 066-1069-02, alternative manufacturer designation 066-01069-0002, model KDI 573, aircraft type, master KDI model, remote transceiver, supply and lighting requirements, connector arrangement, quantity and required certification. Tray, connector, master indicator, transceiver, antenna and wiring are included only when expressly listed. Related avionics can be reviewed in the Garmin / BendixKing / Honeywell / Collins category; final installation approval remains the responsibility of authorized maintenance personnel.

Product Type: Slaved DME indicator / repeater display

Manufacturer: BendixKing / Honeywell

Model: KDI 573

Designation: 066-1069-02

Manufacturer Catalog Designation: 066-01069-0002

Alternative Designations: KDI573; KDI-573; 066106902; 066010690002

Main Function: Repeats compatible DME distance, groundspeed and time-to-station information for an additional crew position

Unit Role: Slaved copilot or crew DME indicator

Typical Signal Chain: Navigation source → KDI 572 or KDI 574 master → remote DME transceiver and antenna → KDI 573 slaved display

Associated Master Indicators: KDI 572 or KDI 574 in an approved configuration

Remote Equipment: Compatible remote DME transceiver required

Year of Manufacturing: 2019 according to the inventory record

Exact Plate Status: A readable -02 identification plate is not available in the reference gallery; verify the allocated unit

Weight: Exact value for Part Number 066-1069-02 not independently confirmed

Exact Dimensions: Refer to the approved KDI 573 installation drawing

Power Supply: Verify through approved data for Part Number 066-1069-02

Connector and Pin Assignment: Verify through the applicable KDI 573 wiring data

Aircraft Applicability: Confirm from the aircraft equipment list and approved DME installation documentation

Interchangeability: Do not substitute KDI 572 or KDI 574 without approved configuration and wiring data

Condition: New / Unused

Warranty: 6 Months

Delivery Set: Master indicator, tray, connector, transceiver, antenna and wiring only when expressly included

Technical Documentation: Applicable BendixKing KDI 573 installation and maintenance data
