066-01141-0201

KT 70 Mode S ATC transponder — 066-01141-0201

066-01141-0201 identifies this BendixKing / Honeywell KT 70 Mode S ATC transponder. The unit provides Mode S surveillance replies in a compatible panel-mounted aircraft installation. This card is based on the exact partner inventory record and the complete designation shown above; it is not a generic listing for every visually similar version in the same equipment family.

The partner source describes the item as: Transponder with Mode S (without Flight ID) Same mounting rack as KT-76C,KT-73, and KT-71 The KT-70 does not meet the ICAO Annex 10 SARPS mandate for Mode S datalink. The source condition is Serviceable. Technical statements in this listing are limited to the exact functions and characteristics documented for this position. Unknown dimensions, current consumption, pin assignments or aircraft applicability are not inferred from a related model.

Operational role and system function

KT 70 is a Mode S transponder without Flight ID capability. The source specifically states that this model does not meet the ICAO Annex 10 SARPs mandate for Mode S datalink, so it must not be represented as an ADS-B solution. In normal service, correct operation also depends on the associated antennas, sensors, control heads, displays, power, grounding and wiring that belong to the approved aircraft installation. A fault indication at one component does not by itself prove that the component is the source of the system fault.

The equipment must be evaluated as part of its complete signal chain. Controls, connectors or labels visible in a photograph confirm physical features of the photographed configuration, but they do not prove that optional functions, software features or approvals are enabled in a particular aircraft. Approved technical data remains the controlling reference.

Installation and connected equipment

The source identifies rack compatibility with KT 76C, KT 73 and KT 71 installations, but electrical and approval compatibility must still be checked. An antenna, altitude source, power, wiring and correct rack connector are required. A rack, backplate, connector kit, antenna, coupler, wiring harness or other installation hardware is not assumed to be included unless it is explicitly named in the quotation or Delivery Set.

Before installation, technicians should compare 066-01141-0201 with the removed unit, aircraft equipment list, wiring diagram, modification status and applicable manufacturer manual. Panel dimensions, mounting depth, connector keying, pin allocation, circuit protection, lighting, cooling, data format and configuration settings all require confirmation. Similar appearance is not evidence of interchangeability.

Configuration checks for 066-01141-0201

The complete designation and suffix are part of the product identity. Hardware revision, modification status, voltage, lighting, software, database, certification and connector configuration can differ between closely related variants. These details should be confirmed against the aircraft records and the specific serial number allocated for supply.

Incoming inspection should verify the manufacturer plate, housing, connectors, locking features, controls, display or indicator face, fasteners and evidence of unauthorized modification. The inspection should also confirm that shipping protection and supplied accessories agree with the quotation. Functional testing should follow the approved bench procedure for the exact model. Installation and return to service remain the responsibility of appropriately authorized personnel.

Serviceable condition, ordering and support

This 066-01141-0201 KT 70 is offered in Serviceable condition from Partner Stock with a six-month warranty. Partner availability can change, so allocation, the available serial number, current test status and release documentation are reconfirmed before order acceptance. Image processing does not alter or upgrade the declared commercial condition.

For an inquiry, specify 066-01141-0201, model KT 70, quantity, destination and documentation requirements. Adding the aircraft type, removed-unit Part Number and installation details helps prevent configuration errors. Buyers may also request current photographs of the allocated serial number and clarification of the quoted delivery set before confirming the order. Packaging and transport arrangements are selected for the destination and the physical characteristics of the unit.

Related avionics are available in the Garmin / BendixKing / Honeywell / Collins category. Cross-sell products are related catalog positions, not interchangeable replacements unless approved data explicitly confirms substitution.

Product Type: Mode s atc transponder

Designation: 066-01141-0201

Manufacturer: BendixKing / Honeywell

Model: KT 70

Function: Provides mode s surveillance replies in a compatible panel-mounted aircraft installation

Transponder Mode: Mode S

Flight ID: Not provided by this configuration

Rack Reference: Same mounting-rack family as KT 76C, KT 73 and KT 71 according to the source

Compliance Note: Does not meet the ICAO Annex 10 SARPs mandate for Mode S datalink according to the source

Partner Inventory Serial Reference: 30142

Condition: Serviceable

Warranty: 6 Months

Installation Note: Confirm exact designation, suffix, serial allocation, rack, connectors, wiring, configuration and aircraft approval before installation

Technical Documentation: Applicable manufacturer installation and maintenance data plus aircraft wiring and approval documentation
