064-1052-70

BendixKing KY 96A transceiver 064-1052-70

064-1052-70 is the exact legacy BendixKing Part Number for this KY 96A VHF communications transceiver. The equivalent expanded manufacturer numbering format is 064-01052-0070. Both numbers identify the Crown-series -70 configuration and are useful when checking inventories, maintenance records and older equipment documentation. The complete suffix should be verified before ordering.

The KY 96A combines VHF receiver, transmitter, frequency display and cockpit controls in one panel-mounted unit. It supports normal pilot communication with air traffic control and other aircraft when connected to the approved antenna, coaxial cable, microphone, audio system, aircraft power and mounting rack. It is not an audio panel and does not replace the functions of an intercom or antenna coupler.

Crown-series face and frequency coverage

Manufacturer documentation identifies 064-1052-70 as the Crown-series version of the 064-1052-60 configuration. It has a solid black face without the silver trim used on certain other KY 96A versions. The -70 unit covers 118.000 to 136.975 MHz in 25 kHz steps and provides 760 available communication frequencies. Its receiver uses 25 kHz selectivity.

This configuration provides an 8 W audio output into a 4-ohm load. The KY 96A family also includes versions with different frequency limits, receiver selectivity and audio-output arrangements. A similar front panel does not prove interchangeability. The exact -70 suffix, 28 V supply, rack, connector keying, audio load and aircraft approval must all be checked before replacement.

Controls, memory and cockpit operation

The front panel presents active and standby frequency windows with a transfer function for moving the standby selection into use. Published product information describes nine programmable memory channels in addition to the displayed frequencies. Non-volatile storage retains selected information without an external backup battery. A compatible remote transfer switch may also be installed where the aircraft wiring provides for that function.

Automatic audio leveling helps control changes in received audio strength, and the display can provide a stuck-microphone indication. The transmitter is documented with at least 5 W RF output and a duty cycle of one minute transmitting followed by four minutes receiving. These features depend on a correct antenna system and installation; radio performance should not be evaluated without checking coaxial losses, microphone level, audio load and aircraft supply voltage.

Electrical, dimensional and environmental data

The KY 96A operates from a 28 V aircraft electrical system. Published data gives a cabinet size of approximately 6.25 in wide, 1.3 in high and 10.50 in long, equivalent to about 158.8 × 33.0 × 266.7 mm. The listed weight is approximately 2.9 lb, or 1.32 kg. Final clearance must also account for the rack, rear connector, wiring bend radius and required cooling space.

The documented operating temperature range is -20 °C to +55 °C. Transmitter qualification is listed under TSO C37c Class 4, while the receiver is associated with TSO C38c and the applicable DO-186 class for the -70 configuration. Installation and post-installation tests must follow the KY 96A / KY 97A manual rather than relying only on product-card values.

Serviceable condition and ordering information

This 064-1052-70 KY 96A is offered in Serviceable condition from partner stock with a six-month warranty. The main image was prepared from the exact photographed unit and retains the authentic Bendix/King Crown-series face, display windows, controls and markings. A reseller label was removed without altering the original radio geometry or technical features; an additional authentic front view is included for condition reference.

For a quotation, specify Part Number 064-1052-70 or expanded number 064-01052-0070, model KY 96A, quantity, aircraft installation and documentation requirements. The mounting rack, connector kit, wiring accessories and release records are included only when expressly confirmed. Other communication and navigation units can be reviewed in the Garmin / BendixKing / Honeywell / Collins category. Related products may share an installation but are not interchangeable without approved technical confirmation.

Product Type: Panel-mounted VHF communications transceiver

Manufacturer: BendixKing / Honeywell

Model: KY 96A

Designation: 064-1052-70

Expanded Manufacturer Number: 064-01052-0070

Alternative Designations: KY96A; KY-96A; 064105270; 064010520070; Bendix/King KY 96A Crown Series

Main Function: Aircraft VHF voice communication reception and transmission

Configuration: Crown-series version of the 064-1052-60 unit with solid black face and no silver trim

Frequency Range: 118.000 to 136.975 MHz

Channel Spacing: 25 kHz

Available Frequencies: 760

Receiver Selectivity: 25 kHz

Audio Output: 8 W into 4 ohms

Transmitter Output: 5 W minimum

Duty Cycle: 1 minute transmit / 4 minutes receive

DC Power Supply: 28 V DC aircraft system

Memory: 9 programmable memory channels in addition to active and standby frequencies

Frequency Transfer: Front-panel flip-flop transfer with provision for a compatible remote switch

Display: Active and standby liquid-crystal frequency display

Operating Temperature Range: -20 °C to +55 °C

Dimensions: Approximately 6.25 × 1.3 × 10.50 in / 158.8 × 33.0 × 266.7 mm

Weight: Approximately 2.9 lb / 1.32 kg

Transmitter Qualification: TSO C37c Class 4

Receiver Qualification: TSO C38c with applicable DO-186 class for the -70 configuration

Installation: Panel installation using the approved rack, connector and antenna system

Connector and Pin Assignment: Verify through the KY 96A / KY 97A installation manual

Interchangeability: Supply voltage, selectivity, audio output, face configuration and complete suffix must be verified

Condition: Serviceable

Warranty: 6 Months

Delivery Set: Rack, connector kit, wiring accessories and release documentation only when expressly included in the quotation

Technical Documentation: KY 96A / KY 97A installation and maintenance data applicable to 064-1052-70
