064-1016-00

BendixKing KCU 951 HF control 064-1016-00

064-1016-00 is the exact Part Number for this BendixKing KCU 951 high-frequency communication control display. The cockpit panel gives the crew access to frequency entry, stored channels, operating mode, clarifier, squelch and volume functions in a compatible HF installation. Its gas-discharge display presents the selected information while the associated receiver-exciter and antenna coupler perform the radio-frequency work elsewhere in the aircraft.

The KCU 951 is a control head, not a complete HF radio. It does not transmit through the antenna or tune the antenna coupler independently of the approved system. A normal functional chain is crew selection on the KCU 951, command transfer through aircraft wiring, transmit and receive processing in the compatible KTR 953, antenna matching by the KAC 952, and radio-frequency operation through the installed HF antenna.

Frequency, channel and mode management

Published KCU 951 information identifies a tuning range extending through 29.9999 MHz and storage for 99 pilot-programmable channels. The front panel includes FREQ-KHZ, CHANNEL, MODE, FREQ/CHAN, clarifier, squelch, volume, store and program controls. A photocell supports display-brightness adjustment for cockpit lighting conditions. Actual available functions depend on the connected system and approved wiring.

The gas-discharge display and rotary controls were designed for direct cockpit operation without opening the remote equipment bay. Frequency selection is processed as a system command, so a blank display, unstable tuning or inability to load the coupler can originate in power, wiring, receiver-exciter or coupler circuits. Troubleshooting should evaluate the complete HF chain before the control panel is condemned.

Operational checks should also confirm that stored channels remain available after a normal power cycle and that cockpit lighting changes do not obscure the selected frequency.

Physical configuration and installation data

Published dimensions for the KCU 951 are approximately 5.75 inches wide, 2.00 inches high and 7.7 inches long. Approximate weight is 1.1 pounds, and the documented operating temperature range is about -20 °C to +55 °C. The exact 064-1016-00 configuration is associated with a black bezel and 28-volt clear lighting. Other suffixes can differ in lighting or installation details.

The panel mounts in an approved cockpit cutout and connects to the aircraft HF system through the specified rear interface. Clearance, connector support, lighting supply and bonding must follow the current installation drawing. Exact pin assignments should never be inferred from another KCU model or copied from a visually similar control. Full suffix control is important when ordering replacement equipment.

KTR 953 and KAC 952 system relationship

In a compatible system, the KCU 951 works with the KTR 953 receiver-exciter and KAC 952 antenna coupler. The receiver-exciter generates and processes the HF signal, while the coupler matches the transmitter to the aircraft antenna. These components are related system units, not interchangeable products and not part of this individual delivery unless they are separately listed in the quotation.

Receiving inspection should verify Part Number 064-1016-00, model KCU 951, control layout, lighting configuration, connector condition, mounting hardware and release documentation. Bench testing should confirm display readability, frequency entry, channel storage and recall, mode selection, clarifier, squelch, volume and communication with compatible KTR 953 test equipment. Aircraft testing should include the antenna and coupler chain.

Serviceable supply and ordering information

This 064-1016-00 KCU 951 is offered in Serviceable condition from partner stock with a six-month warranty. The main image presents a clean front-panel view without a reseller address, and the authentic gallery image preserves the real photographed display, controls and enclosure. The exact Part Number should be verified against the unit documentation because the front panel itself shows the model family rather than the complete suffix.

For an inquiry, specify Part Number 064-1016-00, model KCU 951, aircraft type, KTR 953 and KAC 952 configuration, lighting requirement, release-document requirement and quantity. Other communication controls and associated avionics can be reviewed in the Garmin / BendixKing / Honeywell / Collins category. Related HF units are not automatically interchangeable.

Product Type: HF communication control display

Manufacturer: BendixKing / Honeywell

Model: KCU 951

Designation: 064-1016-00

Alternative Designations: KCU951; KCU-951; 064101600; BendixKing KCU 951

Main Function: Cockpit frequency, channel, mode and audio control for a compatible HF system

Associated Receiver-Exciter: KTR 953

Associated Antenna Coupler: KAC 952

Frequency Range: Up to 29.9999 MHz

Stored Channels: 99 pilot-programmable channels

Display: Gas-discharge display

Brightness Control: Photocell-assisted display brightness

Exact Bezel: Black

Exact Lighting: 28 V clear lighting

Approximate Dimensions: 5.75 in W × 2.00 in H × 7.7 in L

Approximate Weight: 1.1 lb / 0.50 kg

Operating Temperature Range: -20 °C to +55 °C

Qualification References: TSO C31c / C32c and applicable environmental data

Typical Signal Chain: KCU 951 crew input → KTR 953 receiver-exciter → KAC 952 coupler → HF antenna

Aircraft Applicability: Confirm from the aircraft equipment list and approved HF installation

Interchangeability: Verify complete suffix, lighting, connector and system approval

Condition: Serviceable

Warranty: 6 Months

Technical Documentation: Applicable KCU 951 / KTR 953 / KAC 952 installation and maintenance data
