011-02806-00

GNC 255A VHF NAV/COM radio 011-02806-00

011-02806-00 is the exact Part Number for this Garmin GNC 255A VHF NAV/COM radio. The unit combines VHF communication with VOR, localizer and glideslope navigation reception in a panel-mounted radio. This card is tied to the photographed configuration and its exact suffix; it is not a generic listing for every GNC 255A variant or for a visually similar member of the same product family.

The exact source listing identifies Part Number 011-02806-00 as a black-bezel GNC 255A with 8.33 kHz communications spacing and 14/28 V operation. Garmin product data lists 760 communication channels with 25 kHz spacing, 2,280 channels with 8.33 kHz spacing, a 118.000–136.992 MHz communications range and a 9–33 V DC input range for the GNC 255 family. These identification details are retained because software level, voltage, bezel, lighting, options and certification can vary across related versions. The Part Number, installed configuration and approved technical data should therefore be checked together before purchase or installation.

Operational role and capabilities

The GNC 255A gives the crew a controllable communications channel and conventional ground-based navigation capability. Its controls support active and standby frequency management, monitoring, station identification and navigation functions. The unit must operate as part of a complete approved avionics installation. It cannot replace missing antennas, sensors, data sources, indicators, control equipment or aircraft wiring, and the availability of a feature on the faceplate does not by itself prove that the feature is enabled in a particular aircraft.

The practical value of GNC 255A is its ability to place the required function within direct reach of the crew while exchanging the necessary signals with compatible equipment. Correct operation depends on serviceable power, grounds, antennas, data buses, circuit protection, cooling where required and configuration settings. A fault reported at the unit can also originate elsewhere in that connected chain, so troubleshooting should follow approved maintenance procedures.

Installation and connected equipment

A complete installation uses the approved rack and connector kit, a communications antenna, navigation antenna or approved antenna arrangement, audio-panel connections, power and ground, and any supported serial input from a compatible GPS source. The specific aircraft wiring and approval determine which features are enabled. The rack, backplate, connector kit, antenna, wiring and accessories are not assumed to be included unless they are expressly identified in the quotation. Even when two units share a common panel size, their connector keying, pin allocation, software, power requirements and approval basis can differ.

Before installation, technicians should compare 011-02806-00 with the removed unit, aircraft equipment list, wiring diagrams, installation manual and modification records. They should also confirm available panel space, mounting depth, connector condition, antenna compatibility, circuit protection, lighting, cooling and interface configuration. Any substitution requires approved data; similarity of model names or photographs is not evidence of interchangeability.

Configuration checks for 011-02806-00

The complete suffix in 011-02806-00 is an essential part of the product identity. Database status, embedded options, software level, modification status and certification may affect compatibility even when the hardware looks unchanged. These points are especially important when replacing legacy avionics in an aircraft that has accumulated field modifications or multiple supplemental approvals during its service life.

Incoming inspection should verify the manufacturer plate, housing, connectors, locking mechanism, controls, display or indicator face, cooling provisions and evidence of unauthorized modification. Functional testing should use the approved bench procedure for this model. Installation and return to service remain the responsibility of appropriately authorized personnel working to the aircraft and equipment documentation.

Serviceable condition, ordering and support

This 011-02806-00 GNC 255A is offered in Serviceable condition from partner stock with a six-month warranty. Stock status means that availability is based on a partner-held position and should be reconfirmed when a quotation is requested. The allocated serial number, current test status and documentation available for the specific unit are confirmed before order acceptance.

For an inquiry, specify Part Number 011-02806-00, model GNC 255A, required quantity, destination and any installation or documentation requirements. Include the aircraft type and the Part Number of the unit being replaced when possible. Related avionics can be reviewed in the Garmin / BendixKing / Honeywell / Collins category. Products shown together there may be functionally connected, but they are not presented as interchangeable unless approved technical data explicitly authorizes the substitution.

Product Type: Vhf nav/com radio

Designation: 011-02806-00

Manufacturer: Garmin

Model: GNC 255A

Function: VHF communication plus VOR, localizer and glideslope navigation reception

Communication Channel Spacing: 25 kHz and 8.33 kHz

Communication Frequency Range: 118.000–136.992 MHz with 8.33 kHz spacing according to Garmin product data

Input Voltage Range: 9–33 V DC for the GNC 255 family; the source listing identifies 14/28 V operation

Transmitter Power: 10 W for the GNC 255A version according to Garmin product data

Dimensions: 4.19 × 15.88 × 26.42 cm / 1.65 × 6.25 × 10.4 in, excluding rack and rear connector allowance

Weight: 1.37 kg / 3.02 lb unit only; 1.57 kg / 3.46 lb with mounting rack

Condition: Serviceable

Warranty: 6 Months

Installation Note: Confirm the exact Part Number, suffix, software or modification status, rack, connectors, wiring and aircraft approval before installation

Technical Documentation: Applicable manufacturer installation and maintenance data plus aircraft wiring and approval documentation
