Microwave module
1GI03-1/02-2
Price on request
Microwave module
Available on back-order
Description
1GI03-1/02-2 microwave module purpose
1GI03-1/02-2 is a pulsed microwave generator module intended for generation of pulsed microwave oscillations at a fixed frequency with cathode modulation. It operates inside a matched radio-frequency path and is not a complete stand-alone transmitter.
The slash code and execution index identify the specific modification. The full 1GI03-1/02-2 designation should be stated in an inquiry because neighbouring family variants may have different electrical performance and tuning.
Operating principle and equipment role
The module operates in pulsed mode in the decimeter-wave part of the microwave spectrum. It produces radio-frequency oscillations using the modulation method specified for this execution.
The RF path, load and power-supply mode must be matched to the installed equipment. Connector pinout and supply voltages are defined by the product passport and system diagram and are not transferred from visually similar modules.
Confirmed 1GI03-1/02-2 performance
Published data for this modification specify output pulse power 30 W, frequency instability ±0.3 MHz, VSWR ≤ 1.7, mass 270 g. The applicable technical specification is ЖТ0.208.003 ТУ. These values belong to the exact 1GI03-1/02-2 execution.
The numerical values are repeated in Technical Details without condition, warranty, year of manufacture or stock status. Those commercial fields describe the individual unit and are shown separately on the product page.
Installation, compatibility and inspection
Selection checks the complete designation, technical specification, frequency execution, permissible output power, VSWR, mounting dimensions and interface. A similar housing or a matching base index does not establish interchangeability.
Incoming inspection covers the housing, terminals and marking and is followed by testing on suitable RF bench equipment. Operating conditions must be taken from the documentation for the exact module and connected system.
Identification and ordering of 1GI03-1/02-2
An inquiry should include the 1GI03-1/02-2 designation, quantity, required documentation and the equipment in which the module is installed. A clear nameplate photograph or logbook reference should be supplied when available.
Other executions are listed under Electronic Modules. Four related products are selected from the same functional family for navigation only and do not represent a statement of interchangeability.
Technical Details
Product Name: Pulsed microwave generator module 1GI03-1/02-2
Part Number: 1GI03-1/02-2
Cyrillic Designation: 1ГИ03-1/02-2
Product Class: Fixed-frequency microwave generator
Function: Generation of pulsed microwave oscillations at a fixed frequency with cathode modulation
Modulation: Cathode modulation
Output Pulse Power: 30 W
Frequency Instability: ±0.3 MHz
VSWR: ≤ 1.7
Mass: 270 g
Technical Specification: ЖТ0.208.003 ТУ
Selection: By complete designation, technical specification and installed-equipment documentation
