BU-2A Series 3
Flap Control Unit
Description
BU-2A series 3 — verified identity and purpose
BU-2A series 3 is a Series 3 flap-control unit for the SEUZ-1 Series 2 system. The block compares command and feedback potentiometer signals and switches control, indication and synchronization circuits for the aircraft flap-control system. The documented associated mechanisms are MKV-43A Series 2, MKV-42A Series 2 and MKV-41 Series 2.
Full descriptionCollapse description
Function in the installed system
The block must be treated as one element of an installed aircraft system, working with the sensors, command circuits, indicators, actuators or power sources stated in that system documentation. A category label alone does not define pinout or interchangeability. General context is available under aircraft and avionics equipment.
Technical data and system interfaces
The Technical Details below separate confirmed values from points that still require the exact passport. Existing technical values were retained where they were specific to this designation. No voltage, aircraft type, mass or compatibility was copied from a similarly named product.
Identification and compatibility
Confirm the complete designation, suffix, series, drawing number, connector keying and aircraft or system effectivity. Related variants are not automatic substitutes. Photographs of the data plate and connectors are required when the execution cannot be established from the order line alone.
Inspection and ordering
Inspect the housing, mounting points, connectors, seals and markings before testing. Use only the approved procedure for the exact execution. State the full designation, aircraft or system, quantity, condition, delivery set and document requirements in the enquiry. Related items are listed under Electronic Control Units.
Technical details
- Product Type
- Series 3 flap-control unit for the SEUZ-1 Series 2 system
- Primary Designation
- BU-2A series 3
- Original Cyrillic Designation
- БУ-2А серии 3
- Verified Purpose
- The block compares command and feedback potentiometer signals and switches control, indication and synchronization circuits for the aircraft flap-control system. The documented associated mechanisms are MKV-43A Series 2, MKV-42A Series 2 and MKV-41 Series 2.
- Documented System
- SEUZ-1 Series 2
All specificationsCollapse specifications
- Associated Mechanisms
- MKV-43A Series 2, MKV-42A Series 2 and MKV-41 Series 2
- DC Supply
- 27 V
- AC Supply
- 36 V, 400 Hz
- Recorded Current at 36 V / 400 Hz
- Not more than 320 mA
- Duty
- Continuous
- Operating Temperature
- −60 to +60 °C
- Mass
- Not more than 4.3 kg
- Alternative Designations
- BU-2A series 3; BU2A series 3; БУ-2А серии 3
- Interchangeability
- Only after matching the complete nameplate, execution, connectors and system documentation
- Documentation
- Product passport and applicable aircraft/system maintenance documentation
