Voltage Measurement Unit
BIN-3-20D
Price on request
Voltage Measurement Unit
Available on back-order
Description
BIN-3-20D voltage measurement unit
BIN-3-20D is an electrical measurement block identified by the Cyrillic marking БИН-3-20Д. A technical description of equipment carrying this exact designation calls it a voltage measurement unit used as the sensing element in a closed-loop voltage-control chain. An aircraft-industry procurement document also confirms the designation among aviation spares, but does not identify a particular aircraft installation.
Operating role
In the documented control principle, the measurement unit detects deviation of generator voltage from the required level and supplies a proportional signal to the following amplifier and excitation-control stages. This describes its role in an electrical regulating chain, not a complete generator regulator by itself. The broader context is aircraft avionics and electrical equipment; exact generator type and aircraft effectivity remain controlled by the installation documents.
Identification and compatibility
Use the full BIN-3-20D / БИН-3-20Д designation when ordering. The additional letter У found in some technical literature may identify an execution or climatic version and must not be added or removed without checking the nameplate. Similar BIN units can have different thresholds, connector assignments or control circuits. Compare the marking, drawing number, connector, mounting and associated voltage-control equipment.
Inspection and supply
Incoming inspection should cover the enclosure, connector contacts, fastening points, seals and legibility of the plate. Functional testing requires the approved circuit and known supply and signal pins; trial energizing by analogy is unsafe. An enquiry should include photographs of all markings, the aircraft or generator system, quantity, condition and required documentation. Related power and control units are listed under Electronic Control Units.
BIN-3-20D in the BRN-208 regulator
Technical training material places BIN-3-20D inside the BRN-208M7A/M7B generator-voltage regulator used with the GT-40PCh6 aircraft generator. The documented regulator also contains MU1B-62 and MU2B-62 magnetic amplifiers and a three-phase rectifier stage using D237A devices. These names define the verified control-chain context; they are separate components and are not substitutes for BIN-3-20D.
Technical Details
Product Type: Voltage measurement unit
Documented Function: Sensing element in a closed-loop voltage-control chain
Measured Parameter: Generator or regulated-system voltage
Aircraft Context: Confirmed in an aviation-spares procurement list; exact platform not stated
Primary Designation: BIN-3-20D
Original Cyrillic Designation: БИН-3-20Д
Alternative Designations: BIN-3-20D; BIN320D; БИН-3-20Д; БИН320Д
Possible Execution Mark: БИН-3-20Д У appears in technical literature; verify against the plate
Electrical Ratings and Pinout: Verify in the exact passport and system circuit diagram
Selection Basis: Full marking, drawing, connector, mounting and associated regulating system
Documented Regulator: BRN-208M7A/M7B
Documented Generator: GT-40PCh6
Cooperating Units: MU1B-62 and MU2B-62 magnetic amplifiers
Documented Rectifier Stage: Three-phase stage using D237A devices
