BCS-6-1T
Fuel Balancing and Signalling Unit
Description
BCS-6-1T fuel balancing and signalling unit
BCS-6-1T is the common Latin catalogue form of the Russian БЦС6-1Т. Technical descriptions identify it as the balancing and signalling block in the SUIT4-1T fuel control and measurement system. It contains two balancing channels: one for the paired No. 2 tanks and one for the paired No. 3 tanks.
Full descriptionCollapse description
Fuel-balancing functions
During automatic fuel sequencing, the block detects an imbalance between corresponding left and right tanks and commands the transfer-pump channel on the side with less fuel to switch off. The documented thresholds are 350 ±150 kg difference for the No. 2 tanks and 300 +100 kg for the No. 3 tanks. The associated cockpit/engineer-panel indication shows that the balancing logic is active.
SUIT4-1T equipment relationship
BCS-6-1T is installed on the UKB22-1T switching unit within SUIT4-1T. The wider equipment includes BI20-1T measurement blocks, BTP3-1T calibration/programming block, BPS3-1 sum-conversion block, relay blocks and the UTO2-6T total-fuel indicator. The automatic balancing function operates together with the system’s programmed fuel-consumption control.
Documented Tu-154 application and power
The SUIT4-1T system is documented on the Tu-154 family. System power uses 115 V, 400 Hz AC and 27 V DC circuits protected in the aircraft distribution network. These are system-level values; terminal assignments and standalone consumption of BCS-6-1T must come from the unit passport. The related BCS-4-1AT belongs to a different system.
Built-in check and ordering
The front panel provides CHECK No. 2 and CHECK No. 3 controls for the documented built-in test; the corresponding panel indicators are used during the procedure. Before supply, inspect the panel, lamps, buttons, connectors, rack fittings and the complete nameplate. State the aircraft, SUIT4-1T execution, full marking, quantity, condition and documentation requirements. Related products are under Electronic Control Units.
Technical details
- Product Name
- Fuel Balancing and Signalling Unit
- Primary Designation
- BCS-6-1T
- Original Cyrillic Designation
- БЦС6-1Т
- Product Type
- Aircraft fuel-balancing and signalling electronic block
- Documented System
- SUIT4-1T fuel control and measurement system
All specificationsCollapse specifications
- Documented Aircraft
- Tu-154 family
- Balancing Channels
- Two: paired No. 2 tanks and paired No. 3 tanks
- No. 2 Tank Imbalance Threshold
- 350 ±150 kg
- No. 3 Tank Imbalance Threshold
- 300 +100 kg as recorded in the technical source
- Control Action
- Commands the transfer-pump channel on the side with less fuel to switch off and activates indication
- Installation
- On the UKB22-1T switching unit
- Associated Blocks
- BI20-1T, BTP3-1T, BPS3-1, relay blocks and UTO2-6T indicator
- System AC Supply
- 115 V, 400 Hz
- System DC Supply
- 27 V
- Built-In Check
- Front-panel CHECK No. 2 and CHECK No. 3 controls
- Alternative Designations
- BCS-6-1T; BCS6-1T; BTsS6-1T; БЦС6-1Т; БЦС-6-1Т
- Interchangeability
- Not interchangeable with BCS-4-1AT; match the complete SUIT4-1T execution
- Documentation
- Product passport and SUIT4-1T / aircraft technical documentation
