two-position valve
GA-165/1
Price on request
two-position valve
Available on back-order
Description
GA-165/1 Two-position solenoid hydraulic valve
GA-165/1 is a two-position solenoid hydraulic valve that connects a standby hydraulic pumping source to the required aircraft circuit, including emergency landing-gear functions in confirmed installations. The unit is an independent functional component of the applicable onboard system. Selection should be based on the complete designation, working medium, setting and installation diagram rather than appearance alone.
Operating principle of GA-165/1
An electrical command energizes the solenoid and moves the pilot element. Hydraulic pressure then shifts the main valve member to connect or isolate the specified circuit; end-position control depends on the exact execution and aircraft wiring. Reliable operation depends on clean working fluid, the moving element, seat, springs and seals. Contamination, reversed connections or an unsuitable pressure can prevent the intended response.
Role in the aircraft system
Aircraft emergency and reserve hydraulic circuits. Technical records identify GA-165/1 in emergency landing-gear release and in arrangements feeding the first system from a second-system pumping station. The valve works with pipelines, a pressure source, downstream equipment and the control elements of its circuit. These products are functionally related but must not be described as interchangeable merely because they operate in the same system.
Installation and maintenance checks
Before installation, verify the nameplate, ports, flow direction, internal cleanliness and seal condition. Working pressure, temperature, fluid and the prescribed functional test must come from the passport and maintenance documentation. Adjustment without approved instructions is not permitted. Incoming-inspection results should remain with the product records.
Identifying GA-165/1 for ordering
Retain the complete suffix and verify the port arrangement, connector and de-energized position. GA-165, GA-165/1 and GA-165B are related but separate executions. Other related products are listed in the valves category. An enquiry should state the complete designation, execution, condition, delivery set and required supporting documents.
Technical Details
Product Type: Two-position solenoid hydraulic valve
Designation: GA-165/1
Russian Designation: ГА-165/1
Function: connects a standby hydraulic pumping source to the required aircraft circuit, including emergency landing-gear functions in confirmed installations
Operating Principle: An electrical command energizes the solenoid and moves the pilot element. Hydraulic pressure then shifts the main valve member to connect or isolate the specified circuit; end-position control depends on the exact execution and aircraft wiring.
System / Applicability: Aircraft emergency and reserve hydraulic circuits. Technical records identify GA-165/1 in emergency landing-gear release and in arrangements feeding the first system from a second-system pumping station.
Working Medium: AMG-10 hydraulic oil
Operating Pressure: According to the exact product passport and hydraulic-system diagram
Operating Temperature: According to the product passport and aircraft documentation
Installation: According to flow direction, port assignment and the diagram of the specific system
Ordering Check: Retain the complete suffix and verify the port arrangement, connector and de-energized position. GA-165, GA-165/1 and GA-165B are related but separate executions.
Documentation: Product passport, illustrated parts catalogue, system diagram and available test records
