GU-103B

Construction and cooling

The design uses indirectly heated oxide cathode and external forced-air-cooled anode. These features affect equipment layout and installation requirements: the specified connections and heat removal must be provided for the exact tube execution.

Role in RF equipment

Generator tubes are used where high-frequency power must be generated or amplified. Similar dimensions, a related designation or a comparable cooling method do not establish identical electrical characteristics or interchangeability.

Selection and installation

Before ordering or installing, compare the GU-103B designation, terminal layout, mounting panel, electrode voltages, heater mode and cooling arrangement with the equipment passport. For high-power tubes, the air or water path and electrical-safety provisions are essential parts of the installation.

Information for an enquiry

The tube must be installed only with the intended panel and forced-air path. Compare the contact arrangement, control-grid circuit and maximum dissipation with the passport of the equipment, particularly when replacing a removed tube or assembling a high-power RF stage.

Please state the exact designation, quantity, marking photograph, required delivery set and equipment details. This permits a compatibility check for the offered execution without assumptions based on similar models.

Working values and limits are taken from the passport for the exact tube. Where that document is unavailable, ratings must not be copied from another version merely because dimensions, cooling method or part of the designation appear similar.
