12-SAM-28P
Lead-Acid Battery
Description
12-SAM-28P aircraft battery overview
The 12-SAM-28P is an aircraft lead-acid starter battery used in onboard DC power systems. It is intended for aircraft and helicopter applications where an autonomous electrical source is required for engine starting, ground operation, or emergency supply. The battery works as part of the onboard 24 V DC network and can supply current when the main electrical sources are not available. In typical aircraft use, this kind of battery is connected with starter circuits, DC busbars, switching equipment, charging circuits, and emergency consumers.
Full descriptionCollapse description
Starting and emergency power with 12-SAM-28P
The battery is used to support autonomous engine starting and short-term power supply of onboard equipment. On helicopters such as Mi-8, batteries of this type may be used when external power is not connected or when the onboard generators are not yet operating. In emergency conditions, the battery can keep selected DC consumers powered for a limited time, depending on the aircraft electrical scheme and actual battery condition. It should not be treated as a replacement for the main generator system. Its role is reserve and starting power.
Design meaning of the 12-SAM-28P designation
The designation gives a useful technical description of the battery. "12" refers to the number of connected cells in the battery. "SAM" identifies the unit as a starter aviation monoblock battery. "28" indicates the nominal capacity rating. The letter "P" refers to the polypropylene battery case. This marking is important during procurement because similar aircraft batteries may have close dimensions or voltage class but different capacity, case material, terminal arrangement, or service documentation.
Aircraft electrical system around 12-SAM-28P
In an aircraft DC system, the 12-SAM-28P works together with battery contactors, protection devices, charging circuits, DC distribution buses, external power connection circuits, and cockpit indication. If the battery does not support start or the voltage drops too quickly, the cause is not always the battery alone. Maintenance checks usually include charge condition, electrolyte status where applicable, terminal condition, cable connections, charging system operation, and load demand. Battery replacement should follow the aircraft maintenance manual and battery service documentation.
Identification and ordering checks for 12-SAM-28P
Before ordering, the installed battery designation should be checked against the aircraft parts catalog, maintenance documentation, or battery compartment requirements. The 12-SAM-28P may be supplied in a dry-charged condition, depending on supply terms and storage requirements, and commissioning must be carried out according to approved battery documentation. For a clear request, it is useful to specify the aircraft type, required condition, documentation, and whether electrolyte is included or excluded from supply. The product is also known under alternative designation 12-САМ-28П.
Technical details
- Product Type
- Aircraft lead-acid starter battery
- Function
- Autonomous engine starting, emergency and ground DC power supply
- Application / Where Used
- Aircraft and helicopter onboard DC electrical systems
- System / Installation Area
- Battery compartment / 24 V DC onboard network
- Compatible Aircraft / Equipment
- Aircraft and helicopters using 12-SAM-28P type batteries, including Mi-8 applications where confirmed by aircraft documentation
All specificationsCollapse specifications
- Battery Type
- Lead-acid, aviation starter monoblock battery
- Number of Cells
- 12
- Nominal Voltage
- 24 V
- Nominal Capacity
- 28 Ah at 5-hour discharge rate
- Case Material
- Polypropylene
- Condition of Supply
- Dry-charged, without electrolyte, where specified by supply documentation
- Operating Altitude
- Up to 17 km when installed according to aircraft requirements
- Operating Temperature Range
- −50 to +50 °C when used in a thermal container
- Weight Without Electrolyte
- Approx. 22 kg
- Weight With Electrolyte
- 26.5 to 28.5 kg
- Dimensions
- Approx. 370 × 165 × 215 mm
- Assigned Service Life
- 9 years, subject to storage and operation requirements
- Technical Documentation
- Battery passport / aircraft battery maintenance documentation
