6N12S

Double triode 6N12S is designed to amplify low frequency voltage. It can be used to amplify low frequency power in a push-pull circuit. Indirectly heated oxide cathode. Works in any position. Available in glass design. Service life is not less than 500 hours. Octal base with key. Pins 8.

1. Heater voltage 6.3 V.
2. The voltage at the anode is 180 V.
3. The bias voltage on the first grid is 7 V.
4. Heater current 900 – + 70 mA.
5. The current in the anode circuit is 23 ± 8 mA.
6. Current in the anode circuit at a voltage on the grid – 24 V, 100 μA.
7. The difference between the anode currents of the first and second triodes, no more than 5 mA.
8. The slope of the characteristic is 6.4 ± 1.6 ma / v.
9. The slope of the characteristic at a heating voltage of 5.7 V, 4.1 mA / V.
10. Gain – 17 ± 3.
