6E5S

Electronic light indicator 6E5S for visual tuning of radio receivers and tape recorders. Design - in a glass shell, with an octal base. Weight 42 g.

1. Heating voltage – 6.3 V;
2. Voltage at the anode – 250 V;
3. Voltage at the crater – 250 V;
4. Bias voltage on the control grid – -4 V;
5. Glow current – 300 + – 25 mA;
6. Current in the anode circuit – 5.3 + – 1.9 mA;
7. Current in the crater circuit – 5 mA;
8. Slope of the characteristic – 1.2 + – 0.4 mA / V;
9. Amplification factor – 24;
10. Voltage on the grid at an angle of the dark sector no more than 5 degrees – -8.25 + – 2.25.
