ELECTRONIC BEAM TUBE
15LO1I
Price on request
ELECTRONIC BEAM TUBE
Available on back-order
Description
Electron-beam oscillographic tube without memory. Single-beam tube 15LO1I, with an intermediate electrode, shielding plates, a grid and an astigmatism correction anode, with one post-acceleration stage, with a rectangular screen and a parallax-free reading scale. CRT 15LO1I is designed for visual observation and measurement of electrical processes in electronic devices.
Details
1. Screen glow color – green.
2. Screen afterglow is average.
3. The width of the focused line is no more than 0.5 mm.
4. Recording speed is not less than 180 km / s.
5. Design – baseless glass with additional leads on the cylinder and neck.
6. Weight – 1.2 kg.
