ELECTRIC TURN SIGNAL
EUP-53
Price on request
ELECTRIC TURN SIGNAL
Available on back-order
Description
The electric direction indicator EUP-53 is a combined device and consists of a gyroscopic direction indicator and a slip indicator. The direction indicator shows the direction of the turn, and for non-slip turns, the angle of roll up to 45 °. The device has the smallest error (± 1.5 °) at a speed of 500 km / h.
Details
1. Ambient temperature from – 60 to + 60 ° С.
2. Device error, no more than + – 3 ° С.
3. The return time of the hand from the extreme position to the zero mark of the scale is within the range from 1.2 to 3.6 s.
4. Stagnation of the arrow of the device, no more than + – 3 ° С.
5. Altitude, no more than 20,000 m.
6. Consumption current, no more than 0.13 A.
7. Weight, no more than 1 kg.
8. Dimensions 170 x 63.2 x 80 mm.
9. Placement on the aircraft dashboard.
10. MTBF, not less than 1500 flight hours.
Payment & delivery
All shipments are carried out from our international warehouse in Dubai (UAE), as well as from our partners’ remote warehouses.
In Stock — items available in stock at the Dubai warehouse are dispatched within 5–10 business days after receiving 100% prepayment.
Remote Stock — items available at our partners’ remote warehouses are supplied within an average of 30–45 business days after receiving 100% prepayment.
Pre-Order — made-to-order products are manufactured and delivered within an average of 45–60 business days. Payment terms: 50% advance payment to start production, with the remaining 50% paid before dispatch from the Dubai warehouse after full readiness for shipment.
Returns & Changes (Restocking Fee)
For selected items, a RESTOCKING FEE of 10% may apply in case of return, order cancellation, or changes to the order specifications. This condition applies only to certain products and is confirmed at the order approval stage.
Warranty
All products are covered by a standard 6-month warranty.
Extended warranty is available upon request and is agreed individually; it may affect the final product price.
