UGR-4UK Series 3

UGR-4UK Series 3 System Overview

The UGR-4UK Series 3 is an aircraft combined instrument designed as a gyromagnetic radio compass indicator and used within onboard navigation systems. It is applied as part of course systems such as GMK-1 on aircraft and helicopters.

UGR-4UK Series 3 Indication Function

The instrument provides visual indication of aircraft heading, turn angles, and radio bearing data in conjunction with automatic radio compass systems. It enables display of relative bearing and course angle to radio stations, supporting navigation tasks during flight.

UGR-4UK Series 3 Aircraft Application

The unit is installed in aircraft and helicopter cockpits as part of integrated navigation equipment and operates together with radio compass systems such as ARK-9 and ARK-15, providing essential directional information to the flight crew.

UGR-4UK Series 3 System Integration

The instrument features a dual-scale design with a fixed outer scale and a movable inner scale, along with pointer indicators and a course setting mechanism for manual input. It operates as part of navigation and course systems, providing synchronized indication of heading and radio navigation data. The product is also known under designation UGR-4UK Series 3.

Product Type: Gyromagnetic radio compass indicator (combined instrument)
Function: Visual indication of heading, turn angles, and radio bearing data
Application / Where Used: Aircraft and helicopter navigation systems (GMK-1, ARK systems)
System / Installation Area: Cockpit instrument panel

Pointer Error (Course Scale): 1°
Pointer Error (Radio Compass Selsyn, Zero Mark): 0.5°
Pointer Error (Other Marks): 2.5°
Coordination Rate: Not less than 15°/s

Scale Design: Fixed outer scale; movable inner scale
Indicators: Dual pointer indication
Course Setting Mechanism: Manual course setter (gear-type control)

Operating Voltage (DC): 24 V (+30% / −25%)
Operating Voltage (AC): 36 V, 400 Hz
Interfaces: CAN up to 1 Mbit/s

Operating Temperature Range: 0…+50 °C

Technical Documentation: Product passport and manufacturer documentation
