Low-current time relay with non-adjustable (fixed) time delays with one contact output having one changeover contact or with one non-contact output. The RVE3A YAL4.544.000-22 relays are designed for switching DC and AC electrical circuits with a time delay from 0.05 to 900 s.

1. Supply current – constant.
2. Operating supply voltage) 27V.
3. Current consumption at an operating voltage of 32 V:
– no more than 10 mA – before operation;
– 15-45 mA – after operation.
4. Insulation resistance between current-carrying elements, between current-carrying elements and the case, not less than:
– in normal climatic conditions (power circuit de-energized) 200 MΩ.
– in conditions of high humidity 10 MΩ.
— at the maximum temperature (after holding the power supply circuit of the relay under operating voltage) 20 MOhm.
5. Test alternating voltage between current-carrying elements and the case, between current-carrying elements:
– in normal climatic conditions:
– between current-carrying elements and the case 350 V.
– between current-carrying elements 180 V.
– in conditions of high humidity 180 V.
– at a reduced atmospheric pressure of 180 V.
6. Resistance of electrical circuit contacts during delivery (acceptance), measured at voltage (6+1) V and current (1000+10) mA, no more than 1.6 Ohm.
7. Relay weight, no more than 70 g.
8. Temperature change from minus 60 to plus 85 C.
