TIME RELAY
RVE1 RS4.544.000-08
RVE1 RS4.544.000-08
TIME RELAY
Available on back-order
Description
Relay electronic, static, with one changeover contact RVE1 RS4.544.000-08 is designed for switching electrical circuits of direct and alternating current with fixed time delays from 0.05 to 180 s.
Details
1. Supply current – constant.
2. Insulation resistance between current-carrying elements, between current-carrying elements and the case, not less than:
– in normal climatic conditions (power circuit is de-energized) – 200 MΩ.
– in conditions of high humidity – 10 MΩ.
– at the maximum temperature (after holding the relay supply circuit under operating voltage) – 20 MΩ.
3. Test alternating voltage between current-carrying elements and the case, between make contacts:
under normal climatic conditions:
– between current-carrying elements and the case – 350V.
– between closing contacts – 180V.
– in conditions of high humidity – 180V.
– at reduced atmospheric pressure – 180V.
4. The resistance of the electrical contact during the delivery period is not more than 1.6 Ohm.
5. The weight of the relay is not more than 160 g.
Payment & delivery
All shipments are carried out from our international warehouse in Dubai (UAE), as well as from our partners’ remote warehouses.
In Stock — items available in stock at the Dubai warehouse are dispatched within 5–10 business days after receiving 100% prepayment.
Remote Stock — items available at our partners’ remote warehouses are supplied within an average of 30–45 business days after receiving 100% prepayment.
Pre-Order — made-to-order products are manufactured and delivered within an average of 45–60 business days. Payment terms: 50% advance payment to start production, with the remaining 50% paid before dispatch from the Dubai warehouse after full readiness for shipment.
Returns & Changes (Restocking Fee)
For selected items, a RESTOCKING FEE of 10% may apply in case of return, order cancellation, or changes to the order specifications. This condition applies only to certain products and is confirmed at the order approval stage.
Warranty
All products are covered by a standard 6-month warranty.
Extended warranty is available upon request and is agreed individually; it may affect the final product price.
